OMRON CJ1W-OD203 CJ1W-OD203 CJ1W0127M CJ1WOD203 OMRON Module 8 Outputs NPN 0.5 TO Term. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

CJ1W-OD203 CJ1W0127M CJ1WOD203 OMRON Module 8 Outputs NPN 0.5 TO Term.

CJ1W-OD203

CJ1W0127M

CJ1WOD203

OMRON

1 Pcs.

Module 8 Outputs NPN 0.5 TO Term. Digital output unit, 8 x transistor outputs, NPN, 0.5 A, 24 VDC, screw terminal

Automation > PLC digital I/O-module
CJ1

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

An Omron module, part number CJ1W-OD203, operates as a digital output unit that bridges controller logic with plant-floor actuators like contactors, indicator lamps, and solenoid valves. Output modules of this standard variety give industrial control systems the capability to switch loads safely based on real-time processing data. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Type of voltage (input voltage) (EF003033): DC
  • Type of output voltage (EF008222): DC
  • Performance level according to EN ISO 13849-1 (EF007399): Level a
  • Type of digital output (EF003601): Transistor
  • Type of electric connection (EF003961): Screw connection
  • Voltage type (supply voltage) (EF002991): DC
  • Digital inputs configurable (EF008516): No
  • Digital outputs configurable (EF008520): Yes
  • Appendant operation agent (Ex ib) (EF004142): No
  • Appendant operation agent (Ex ia) (EF004141): No
  • Redundancy (EF003156): No
  • Suitable for safety functions (EF001597): No
  • Short-circuit protection, outputs available (EF003203): No
  • Number of digital outputs (EF001993): 8
  • Output current (EF003202): 0.5 A
  • Width (EF000008): 31 mm

More info

▲
I/O systemCJ I/O BusExpansion unit typeBasic I/O UnitType of moduleDigital I/ONumber of digital inputs0Digital input typeNoneNumber of digital outputs8Digital output typeNPNPermitted voltage at output10.2-26.4 VOutput current0.5 AShort-circuit protected outputsI/O connection typeScrewNumber of I/O connectors1Detachable I/O connectorSuitable for safety functionsNumber of IOV (V+) terminals1Number of IOG (V-) terminals1Number of COM terminals0Product Height (unpacked)90 mmProduct Width (unpacked)31 mmProduct Depth (unpacked)89 mmProduct Weight (unpacked)110 g

Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
