OMRON A1000-FIA3480-RE A1000-FIA3480-RE 328915 A1000FIA3480RE OMRON Filter input 400V three-phase 480A (A1000-L1000)

View larger

Images are for illustrative purposes only. Please refer to data sheet for details

A1000-FIA3480-RE 328915 A1000FIA3480RE OMRON Filter input 400V three-phase 480A (A1000-L1000)

Name: A1000-FIA3480-RE 328915 A1000FIA3480RE OMRON Filter input 400V three-phase 480A (A1000-L1000)
Brand: OMRON
SKU: 328915

Reference: A1000-FIA3480-RE

Code: 328915

Catalog Number: A1000FIA3480RE

Manufacturer: OMRON

Units per package: 1 Pcs.

Description:

Filter input 400V three-phase 480A (A1000-L1000) Input filter 400V three-phase 480A (A1000-L1000)

Categories:
Automation > Accessories/spare parts for frequency controller
Accessories

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Guarantee, repair and return.

More info

▲

Current vector control, with or without PG
High starting torque (200% / 0.3 Hz, spd range 1:200 OLV), (200% at 0 r/min, spd range 1:1500 CLV)
Double rating ND 120%/1min and HD 150%/1 min
Advanced Auto-Tuning for IM & PM Motors
Open Loop Control of PM Motors
Low-noise Low carrier technology
10 years lifetime design
Screw-less terminals
Control Terminals with memory backup
24 VDC control board power supply option
Fieldbus communications: Modbus, Profibus, CANopen, DeviceNet, ML-II, PROFINET, EtherCAT and EtherNet/IP
Safety embedded: EN954-1 safety cat. 3, stop category 0, IEC EN 61508 SIL 2 and EN61800-5-1 with EDM
Regenerative solutions as option
CE, UL, cUL and TUV

Accessories

Regenerative accessories

D1000 kit - DC Supply with Regenerative Active Front End system

Regenerative DC bus supply unit (D1000)

Reference: CIMR-DC_	4A0005	4A0010	4A0020	4A0030	4A0040	4A0060	4A0100	4A0130	4A0185	4A0270	4A0370	4A0630
Max. applicable motor capacity (kW)	3.7	7.5	15	22	30	45	75	110	160	220	315	560
Rated output capacity (kW)1	5	10	20	30	40	60	100	130	185	270	370	630
Rated input current AC (A)	8	16	30	43	58	86	145	210	300	410	560	1040
Rated output current DC (A)	8	15	30	45	61	91	152	197	280	409	561	955
Rated input voltage	3-phase 380 to 480 VAC
Rated output voltage	660 VDC
Rated frequency	50/60 Hz
Input power factor	> 0.99
Carrier frequency	6						4			2
Degree of protection	IP20 (CIMR-DC4A0005 to CIMR-DC4A0020 models) IP00 (CIMR-DC4A0030 to CIMR-DC4A0630 models)
Ambient humidity	95% RH or less (without condensation)
Storage temperature	-20 to 60ºC
Ambient temperature	-10 to 50ºC

EMC filter

Reference: B84143_	A0020R106	A0035R106	A0065R106	B0180S080	B0400S080	B1000S080	B1600S080
Rated current (A)	20	35	65	180	400	1000	1600
Leakage current (mA)	3.1	3.4	3.4	< 21	< 21	< 40	< 40
Rated voltage	300/520 VAC
Rated frequency	50/60 Hz
Rated temperature	50ºC
Degree of protection	IP20

Low harmonic filter

Reference: B84143G_	0008R176	0016R176	0030R176	0043R176	0058R176	0086R176	0145R176	0210S176	0300S176	0410S176	0560S176	1140S176
Rated current (A)	8	16	30	43	58	86	145	210	300	410	560	1140
Heat loss (W)2	75	140	165	240	260	300	515	665	855	1398	1970	4015
Rated voltage	305/530 VAC
Rated frequency	50/60 Hz
Rated temperature	50ºC
Degree of protection	IP00

R1000 kit - Regenerative Braking unit system

Regenerative Braking unit (R1000)

Reference: CIMR-RC_	4A03P5	4A0005	4A0007	4A0010	4A0014	4A0017	4A0020	4A0028	4A0035	4A0043	4A0053	4A0073	4A0105	4A0150	4A0210	4A0300
Max. applicable motor capacity (kW)	3.7	5.5	7.5	11	15	18.5	22	30	37	45	55	75	110	160	220	315
Rated output capacity (kW)3	3.5	5	7	10	14	17	20	28	35	43	53	73	105	150	210	300
Rated input current AC (A)	5	8	11	16	22	27	32	43	54	66	81	110	161	237	326	466
Rated output current DC (A)	7	11	15	22	30	36	43	58	73	89	109	149	217	320	440	629
Rated input voltage	3-phase 380 to 480 VAC
Rated frequency	50/60 Hz
Power factor	> 0.9 at full load
Degree of protection	IP20 (CIMR-RC4A03P5 to CIMR-RC4A0028 models) IP00 (CIMR-RC4A0035 to CIMR-RC4A0300 models)
Ambient humidity	95% RH or less (without condensation)
Storage temperature	-20 to 60ºC
Ambient temperature	-10 to 50ºC

Current suppression reactor

Reference: B150_	9105	9106	9107	9108	9109	9110	4118	9111	9112	9113	9114	5002	5008	5011
Rated current (A)	7.5	10	15	25	30	40	50	60	75	100	161	237	326	466
Inductance (mH)	1.2	0.6	0.4	0.3	0.2	0.15	0.12	0.1	0.08	0.06	0.04	0.03	0.02	0.013
Heat loss (W)	21	19	23	36	33	40	46	56	81	72	95	105	120	160

1.Rated output capacity is calculated with a rated input voltage of 400 V.

2.Heat loss at nominal current and 20ºC winding temperature with harmonics.

3.Rated output capacity is calculated with a rated input voltage of 400 V.
