OMRON E3F1-DN22 E3F1-DN22 E3F12007F E3F1DN22OMI OMRON Plastic Reflex 300mm NPN M12 Connector Lite View larger
Images are for illustrative purposes only. Please refer to data sheet for details

E3F1-DN22 E3F12007F E3F1DN22OMI OMRON Plastic Reflex 300mm NPN M12 Connector Lite

E3F1-DN22

E3F12007F

E3F1DN22OMI

OMRON

1 Pcs.

Plastic Reflex 300mm NPN M12 Connector Lite Photoelectric sensor, M18 threaded barrel, plastic, red LED, diffuse, 300 mm, NPN, Light-ON/Dark-ON, M12 connector

Automation > Diffuse reflective photoelectric sensor
E3F1

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

An Omron plastic reflex photoelectric sensor, part number E3F1-DN22, detects object movement and positioning in automated packaging and conveying systems. Threaded cylindrical housings allow for secure mechanical mounting.

Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Voltage type (EF000187): DC
  • Construction type housing (EF004008): Cylinder, screw-thread
  • Degree of protection (IP) (EF005474): IP66
  • Setting procedure (EF003994): Manual adjustment
  • Material of optical surface (EF004134): Plastic
  • Sensing mode (EF007503): Light-/dark switching
  • Type of switch function (EF003963): Programmable/configurable
  • Type of electric connection (EF003961): Connector M12
  • Housing material (EF001596): Plastic
  • Type of light (EF004029): Polarity free red light
  • Material of cable sheath (EF004136): Polyvinyl chloride (PVC)
  • Type of switching output (EF003962): NPN
  • Operation agent-safety class (EF003982): Safety class 3
  • With communication interface RS-485 (EF007314): No
  • Analogue output -10 V ... +10 V (EF006809): No
  • With communication interface SSD (EF007315): No

More info

▲
ShapeCylindrical axialSensing methodDiffuse reflectiveSensing distance300 mmSetting methodManual adjustmentConnection methodConnector M12Output typeNPNOperation modeDark-ON, Light-ONResponse time0.5 msMaterial housingABSThread sizeM18Product Length (unpacked)34.5 mmType of lightPolarity free red lightPower supply voltage10-30 VDegree of protection (IP)IP66
