OMRON NSH5-422CW-10M NSH5-422CW-10M NS050702G NSH5422CW10M OMRON Cable NSH5 connection RS422 connector (9-pin + cable leading)

View larger

Images are for illustrative purposes only. Please refer to data sheet for details

NSH5-422CW-10M NS050702G NSH5422CW10M OMRON Cable NSH5 connection RS422 connector (9-pin + cable leading)

Name: NSH5-422CW-10M NS050702G NSH5422CW10M OMRON Cable NSH5 connection RS422 connector (9-pin + cable leading)
Brand: OMRON
SKU: NS050702G

Reference: NSH5-422CW-10M

Code: NS050702G

Catalog Number: NSH5422CW10M

Manufacturer: OMRON

Units per package: 1 Pcs.

Description:

Cable NSH5 connection RS422 connector (9-pin + cable leading) NSH5 cable, 10 m (RS-422A communications, 24VDC, function key + E-stop + enabling switch wires), non UL-approved

Categories:
Automation > Telecommunications patch cord
HMI Accessories

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Guarantee, repair and return.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Omron NSH5-422CW-10M is a 10-meter RS422 connection cable equipped with a 9-pin connector and cable leading, designed for long-range handheld terminal integration. Robust industrial communication cables support reliable data exchange between remote operator pendants and main control panels. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

NSH5: TFT, 5.7", 320×240 pixels
Bracket NS handheld for wall mounting: NSH5-ATT02
Cable NS handheld, RS-422, 10m UL: NSH5-422UL-10M
Cable NS handheld, RS-232, 10m UL: NSH5-232UL-10M
Cable NS handheld, RS-232, 3m UL: NSH5-232UL-3M
Memory card interface: 1 slot ATA Compact Flash card
Serial (COM1): 1×RS-232/RS-422A
USB Slave: For programming
Line voltage: 24 VDC ±15%
Power consumption: 10 W max.
Battery: CJ1W-BAT01
Battery lifetime: 5 years (at 25°C)
Enclosure rating: IP65 1
Obtained standards: UL 1604 Class 1 Diff. 2, cUL, CE, NEMA equivalent
Operating environment: No corrosive gases
Noise immunity: Conforming to IEC 61000-4-4: 2 kV (power supply line)

More info

▲

Re-use projects of non-mobile NS products
10 Function keys, 4 hardwired for inching
Emergency switch on front plus enable switch on back of unit
Well protected against water, IP65
Compact Flash, Serial and USB interface

Specifications & ordering info

Ordering information

Type			Order code
NSH5	TFT, 5.7", 320×240 pixels	Black	NSH5-SQR10B-V2

Accessories

Type			Order code
Bracket NS handheld protecting emergency button from accidental activation			NSH5-ATT01
Bracket NS handheld for wall mounting			NSH5-ATT02
Cable NS handheld, RS-422, 10m UL			NSH5-422UL-10M
Cable NS handheld, RS-232, 10m UL			NSH5-232UL-10M
Cable NS handheld, RS-232, 3m UL			NSH5-232UL-3M

Specifications

Memory card interface	1 slot ATA Compact Flash card
Serial (COM1)	1×RS-232/RS-422A
USB Slave	For programming
Line voltage	24 VDC ±15%
Power consumption	10 W max.
Battery	CJ1W-BAT01
Battery lifetime	5 years (at 25°C)
Enclosure rating	IP651
Obtained standards	UL 1604 Class 1 Diff. 2, cUL, CE, NEMA equivalent
Operating environment	No corrosive gases
Noise immunity	Conforming to IEC 61000-4-4: 2 kV (power supply line)
Ambient operating temperature	0 to 40°C
Ambient operating humidity	35% to 85% max. (with no condensation)
Vibration resistance (during operation)	10 to 57 Hz with amplitude of 0.075 mm, 57 to 150 Hz with acceleration of 9.8 m/s2 three minutes each in X, Y, and Z directions
Shock resistance (during operation)	147 m/s2 three times each in X, Y, and Z directions
Drop test1	Dropped from 1 m. Conforming to JIS B 3502/IEC61131-2

1.see manual for details.

Accessories

Ordering information

Type	Description		Order code
Cable	Serial programming cable		XW2Z-S002
Cable	USB programming cable, 2 m		CP1W-CN221
PT-to-PLC Connecting Cable	PT connection: 9 pins PLC connection: 9 pins	Length: 2 m	XW2Z-200T
PT-to-PLC Connecting Cable	PT connection: 9 pins PLC connection: 9 pins	Length: 5 m	XW2Z-500T
Accessories	Video input	Inputs: 4 channels NTSC / PAL	NS-CA001
	Video input	Inputs: 2 channels NTSC / PAL, 1 channel RGB	NS-CA002
	Cable to connect NS-CA00_ to Video console unit		F150-VKP (2 m)
	Cable to connect NS-CA00_ to Video console unit		F150-VKP (5 m)
	Controller link interface unit		NS-CLK21
	RS-422A/485 adapter (50 m)		CJ1W-CIF11
	RS-422A adapter (500 m)		NS-AL002
	Anti-reflection sheets (5 sheets)	NS15	NS15-KBA04
		NS12/10	NS12-KBA04
		NS8	NS7-KBA04
		NS5	NT30-KBA04
	Anti-reflection protective covers (5 pack)	NS12/10	NS12-KBA05
		NS8	NS7-KBA05
		NS5	NT31C-KBA05
	Transparent protective covers (5 pack)	NS15 (1 cover)	NS15-KBA05N
		NS12/10	NS12-KBA05N
		NS8	NS7-KBA05N
		NS5	NT31C-KBA05N
	Chemical-resistant cover (1 cover)	NS5	NT30-KBA01
	Attachment adapter	(NT625C/631/631C series to NS12 series)	NS12-ATT01
		(NT625C/631/631C series to NS12 series) Black	NS12-ATT01B
		(NT620S/620C/600S series to NS8 series)	NS8-ATT01
		(NT600M/600G/610G/612G series to NS8 series)	NS8-ATT02
	Memory card	128 MB	HMC-EF183
		256 MB	HMC-EF283
		512 MB	HMC-EF583
	Memory card adapter for PC		HMC-AP001
	Battery		CJ1W-BAT01
