OMRON NJ501-R420 NJ501-R420 NX010228A NJ501R420 OMRON Robotic Integrated Controller NJ5: 8 robots and 32 servo axes, SQL clie.. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

NJ501-R420 NX010228A NJ501R420 OMRON Robotic Integrated Controller NJ5: 8 robots and 32 servo axes, SQL clie..

NJ501-R420

NX010228A

NJ501R420

OMRON

1 Pcs.

Robotic Integrated Controller NJ5: 8 robots and 32 servo axes, SQL client

Automation > PLC CPU-module
Machine Controllers NJ5

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Omron NJ501-R420 robotic integrated controller operates as an advanced automation processor built to seamlessly combine high-speed logic control with coordinated multi-axis motion and database connectivity. Systems like this centralize industrial machine management, handling complex kinematics and peripheral network exchanges within automated production lines. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Model (EF000010): Modular
  • Voltage type (supply voltage) (EF002991): AC/DC
  • Type of memory (EF002996): FLASH
  • Radio standard UMTS (EF008525): No
  • Supporting protocol for EtherCAT (EF017564): Yes
  • Appendant operation agent (Ex ib) (EF004142): No
  • Supporting protocol for other bus systems (EF003062): Yes
  • Supporting protocol for SERCOS (EF006657): No
  • IO link master (EF007298): No
  • Rack-assembly possible (EF007018): No
  • Supporting protocol for KNX (EF003055): No
  • Supporting protocol for LON (EF003017): No
  • Supporting protocol for SUCONET (EF003060): No
  • Supporting protocol for IEC 60870 (EF016069): No
  • Supporting protocol for EtherNet/IP (EF007521): Yes
  • Supporting protocol for DNP3 (EF016068): No

More info

▲
Controller functionalityDB connection, Motion control, Robotics, Sequence controlMax. number of robots8Max. number of synchronous axes32Max. number of axes (incl. virtual)32Primary task cycle time0.5 msProgram memory20 MBVariables memory6 MBCommunication port(s)EtherCAT Master, EtherNet/IP, USBCommunication option(s)CAN, CompoNet Master, DeviceNet Master, DeviceNet Slave, EtherCAT Slave, MODBUS Master, MODBUS Slave, PROFIBUS DP Master, PROFIBUS DP Slave, PROFINET Master, Serial RS-232C, Serial RS-422, Serial RS-485Max. number of remote I/O nodes192I/O systemCJ I/O BusMax. number of expansion units40Product Weight (unpacked)673.752 g
