OMRON NJ501-R320 NJ501-R320 NX010227C NJ501R320 OMRON Robotic Integrated Controller NJ5: 8 robots and 16 servo axes, SQL clie.. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

NJ501-R320 NX010227C NJ501R320 OMRON Robotic Integrated Controller NJ5: 8 robots and 16 servo axes, SQL clie..

NJ501-R320

NX010227C

NJ501R320

OMRON

1 Pcs.

Robotic Integrated Controller NJ5: 8 robots and 16 servo axes, SQL client

Automation > PLC CPU-module
Machine Controllers NJ5

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

An Omron NJ501-R320 Robotic Integrated Controller functions as a centralized processing unit within complex industrial automation networks, coordinating multi-axis motion and machine logic to streamline automated manufacturing workflows. Programmable controllers of this type are widely utilized in modern factory floors to manage synchronized movements, machine vision integration, and communication across various industrial fieldbuses. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Model (EF000010): Modular
  • Voltage type (supply voltage) (EF002991): AC/DC
  • Type of memory (EF002996): FLASH
  • Radio standard UMTS (EF008525): No
  • Supporting protocol for EtherCAT (EF017564): Yes
  • Appendant operation agent (Ex ib) (EF004142): No
  • Supporting protocol for other bus systems (EF003062): Yes
  • Supporting protocol for SERCOS (EF006657): No
  • IO link master (EF007298): No
  • Rack-assembly possible (EF007018): No
  • Supporting protocol for KNX (EF003055): No
  • Supporting protocol for LON (EF003017): No
  • Supporting protocol for SUCONET (EF003060): No
  • Supporting protocol for IEC 60870 (EF016069): No
  • Supporting protocol for EtherNet/IP (EF007521): Yes
  • Supporting protocol for DNP3 (EF016068): No

More info

▲
Controller functionalityDB connection, Motion control, Robotics, Sequence controlMax. number of robots8Max. number of synchronous axes16Max. number of axes (incl. virtual)16Primary task cycle time0.5 msProgram memory20 MBVariables memory6 MBCommunication port(s)EtherCAT Master, EtherNet/IP, USBCommunication option(s)CAN, CompoNet Master, DeviceNet Master, DeviceNet Slave, EtherCAT Slave, MODBUS Master, MODBUS Slave, PROFIBUS DP Master, PROFIBUS DP Slave, PROFINET Master, Serial RS-232C, Serial RS-422, Serial RS-485Max. number of remote I/O nodes192I/O systemCJ I/O BusMax. number of expansion units40Product Weight (unpacked)550 g
