Product Overview
Providing expanded auxiliary contact capabilities, the Omron J77MN-20S side-mount unit adds switching channels to compatible motor protection circuit breakers. Auxiliary blocks are routinely integrated into motor control centers to relay status signals and interlock control logic with starter circuits. Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- 0.25: 0.06
- 0.4: 0.09
- 0.63: 0.18
- 1: 0.25
- 1.6: 0.55
- 2.5: 0.75
- 4: 1.5
- 6: 2.2
- 8: 3
- 10: 4
- 13: 5.5
- 17: 7.5
- 22: 7.5
- 26: 11
- 32: 15
- 0.25: 0.06
- Available rated operational currents to 32 A, 63 A and 100 A
- Switching capacity is mainly 50 kA/400 V or 100 KA/400 V
- All Motor Protection Circuit breaker can be mounted on a DIN-rail
- For the range to 32A we provide electro-mechanical links modules
- All components are finger proof
Specifications & ordering info
Ordering information
Rated current in A | Suitable for motors
3 ~ 400 V kW | Current setting range | Short-circuit breaking capacity at 3 ~ 400 V kA | Size in mm (H × W × D) | Order code |
|---|
Thermal
overload release A | Instantaneous
short-circuit release A |
|---|
0.16 | - | 0.10- 0.16 | 2.1 | 100 | 98 × 45 × 75 | J7MN-3P-E16 |
0.25 | 0.06 | 0.16-0.25 | 3.3 | 100 | J7MN-3P-E25 |
0.4 | 0.09 | 0.25-0.4 | 5.2 | 100 | J7MN-3P-E4 |
0.63 | 0.18 | 0.4-0.63 | 8.2 | 100 | J7MN-3P-E63 |
1 | 0.25 | 0.63-1 | 13 | 100 | J7MN-3P-1 |
1.6 | 0.55 | 1-1.6 | 20.8 | 100 | J7MN-3P-1E6 |
2.5 | 0.75 | 1.6-2.5 | 32.5 | 100 | J7MN-3P-2E5 |
4 | 1.5 | 2.5-4 | 52 | 100 | J7MN-3P-4 |
6 | 2.2 | 4-6 | 78 | 100 | J7MN-3P-6 |
8 | 3 | 5-8 | 104 | 100 | J7MN-3P-8 |
10 | 4 | 6-10 | 130 | 50 | J7MN-3P-10 |
13 | 5.5 | 9-13 | 169 | 50 | J7MN-3P-13 |
17 | 7.5 | 11-17 | 221 | 20 | J7MN-3P-17 |
22 | 7.5 | 14-22 | 286 | 15 | J7MN-3P-22 |
26 | 11 | 18-26 | 338 | 15 | J7MN-3P-26 |
32 | 15 | 22-32 | 416 | 15 | J7MN-3P-32 |
0.16 | - | 0.10-0.16 | 2.1 | 100 | 98 × 45 × 100 | J7MN-3R-E16 |
0.25 | 0.06 | 0.16-0.25 | 3.3 | 100 | J7MN-3R-E25 |
0.4 | 0.09 | 0.25-0.4 | 5.2 | 100 | J7MN-3R-E4 |
0.63 | 0.18 | 0.4-0.63 | 8.2 | 100 | J7MN-3R-E63 |
1 | 0.25 | 0.63-1 | 13 | 100 | J7MN-3R-1 |
1.6 | 0.55 | 1-1.6 | 20.8 | 100 | J7MN-3R-1E6 |
2.5 | 0.75 | 1.6-2.5 | 32.5 | 100 | J7MN-3R-2E5 |
4 | 1.5 | 2.5-4 | 52 | 100 | J7MN-3R-4 |
6 | 2.2 | 4-6 | 78 | 100 | J7MN-3R-6 |
8 | 3 | 5-8 | 104 | 100 | J7MN-3R-8 |
10 | 4 | 6-10 | 130 | 100 | J7MN-3R-10 |
13 | 5.5 | 9-13 | 169 | 100 | J7MN-3R-13 |
17 | 7.5 | 11-17 | 221 | 50 | J7MN-3R-17 |
22 | 7.5 | 14-22 | 286 | 50 | J7MN-3R-22 |
26 | 11 | 18-26 | 338 | 50 | J7MN-3R-26 |
32 | 15 | 22-32 | 416 | 50 | J7MN-3R-32 |
26 | 12.5 | 18-26 | 338 | 50 | 140 × 55 × 144 | J7MN-6R-26 |
32 | 15 | 22-32 | 416 | 50 | J7MN-6R-32 |
40 | 18.5 | 28-40 | 520 | 50 | J7MN-6R-40 |
50 | 22 | 34-50 | 650 | 50 | J7MN-6R-50 |
63 | 30 | 45-63 | 819 | 50 | J7MN-6R-63 |
63 | 30 | 45-63 | 819 | 50 | 165 × 70 × 171 | J7MN-9R-63 |
75 | 37 | 55-75 | 975 | 50 | J7MN-9R-75 |
90 | 45 | 70-90 | 1170 | 50 | J7MN-9R-90 |
100 | - | 80-100 | 1300 | 50 | J7MN-9R-100 |
Accessories
Description | Version | For circuit breaker | Order code |
|---|
Transverse auxiliary contact block |
|---|
Contact block | 1 NO + 1 NC | All | J77MN-11F |
2NO | J77MN-20F |
2NC | J77MN-02F |
Auxiliary contact block for left hand side mounting (max. 2 pc. per circuit breaker) |
Contact block (9 mm) | 1 NO + 1 NC | All | J77MN-11S |
2NO | J77MN-20S |
2NC | J77MN-02S |
Signalling switch for left hand side mounting (max. 1 pc. per circuit breaker) |
Signalling switch (18 mm) | 1 NO + 1 NC any tripping condition | J7MN-3P/-3R | J77MN-TA-11S |
J7MN-6R/-9R | J77MN-TB-11S |
1 NO + 1 NC short circuit tripping condition | All | J77MN-T-11S |
Undervoltage releases for right hand side mounting (max 1 pc. per circuit breaker) |
| AC 50 Hz | AC 60 Hz |
|
|
Trips the circuit breaker when the voltage is interrupted. Prevents the motor from being restarted accidentally when the voltage is restored, suitable for EMERGENCY STOP according to VDE 0113 | 24 V | 28 V | All | J77MN-U-24 |
110-127 V | 120 V | J77MN-U-110 |
220-230 V | 240-260 V | J77MN-U-230 |
240 V | 277 V | J77MN-U-240 |
380-400 V | 440-460 V | J77MN-U-400 |
415-440 V | 460-480 V | J77MN-U-415 |
Shunt releases for right hand side mounting (max 1 pc. per circuit breaker) |
| AC 50 Hz | AC 60 Hz |
|
|
Trips the circuit breaker when the
release coil is energized | 24 V | 28 V | All | J77MN-S-24 |
110-127 V | 120 V | J77MN-S-110 |
220-230 V | 240-260 V | J77MN-S-230 |
240 V | 277 V | J77MN-S-240 |
380-400 V | 440-460 V | J77MN-S-400 |
415-440 V | 460-480 V | J77MN-S-415 |
Terminal block |
Terminal block | Up to 600 V according to UL 489 not for transverse auxiliary
contact block | J7MN-3R | J77MN-TB32 |
J7MN-9R | J77MN-TB100 |
Insulated 3-Phase Busbar System IP20
Description | Connection type | Version | For Units (MPCB) | Order code |
|---|
3-phase busbars;
modular spacing = 45 mm | Spade | for 2 units | J7MN-3P; J7MN-3R | J77MN-CPM-3-45-2S |
for 3 units | J77MN-CPM-3-45-3S |
for 4 units | J77MN-CPM-3-45-4S |
for 5 units | J77MN-CPM-3-45-5S |
Line side terminal 3-pole,
connection from above;
conductor cross-section solid or stranded 6-25 mm²
with end sleeve 4-16 mm² | Spade | acc. IEC/EN 60947-1, 60947-2, 60947-4-1 and VDE 0660 | J7MN-3P; J7MN-3R | J77MN-BTC-63-SE |
Line side terminal 3-pole,
connection from above;
conductor cross-section solid or stranded 6-25 mm²
with end sleeve 4-16 mm² | Spade | up to 600 V acc. UL 489 | J7MN-3P; J7MN-3R | J77MN-BTC-63-SEV |
Shrouds for unused terminals on busbar system | Spade |
| J7MN-3P; J7MN-3R | J77MN-TA-63S |
Specifications
Type | J7MN-3P | J7MN-3R | J7MN-6R | J7MN-9R |
|---|
Number of poles | 3 | 3 | 3 | 3 |
Max. rated current Inmax
(= max. rated operational current Ie) | A | 32 | 32 | 63 | 100 |
Permissible ambient temperature | Storage/transport | -50 to 80°C |
Operation | -20 to 60°C |
Rated operational voltage Ue | V | 690 |
Rated frequency | Hz | 50/60 |
Rated insulation voltage Ui | V | 690 |
Rated impulse withstand voltage Uimp | kV | 6 |
Utilization category | IEC 60 947-2 (circuit breaker) | A |
IEC 60 947-4-1 (motor starter) | AC-3 |
Class | According to IEC 60 947-4-1 | 10 |
Degree of protection | According to IEC 60 529 | IP20 | IP20 | IP20 | IP20 |
Phase failure sensitivity | According to IEC 60 947-4-1 | Yes |
Explosion protection | According to EC Directive 94191EC | Yes |
Isolator characteristics | According to IEC 60 947-3 | Yes |
Main and EM. STOP switch characteristics | According to IEC 60 204-1 (VDE113) | Yes |
Safe isolation between main and auxiliary circuits According to DIN VDE 0106 Part 101 | Up to 400 V + 10% | Yes |
Up to 415 V + 5% | Yes |
Mechanical endurance | Operating cycles | 100,000 | 100,000 | 50,000 | 50,000 |
Electrical endurance | 100,000 | 100,000 | 25,000 | 25,000 |
Max. operating frequency per hour (motor starts) | 1/h | 25 | 25 | 25 | 25 |
