> OMRON > Photoelectric sensors > E3T > E3T 1035M
OMRON E3T-FD13 2M E3T-FD13 2M E3T 1035M E3TFD132M OMRON Thumbnail 3h Dslr 30mm Flat PNP Light View larger
Images are for illustrative purposes only. Please refer to data sheet for details

E3T-FD13 2M E3T 1035M E3TFD132M OMRON Thumbnail 3h Dslr 30mm Flat PNP Light

E3T-FD13 2M

E3T 1035M

E3TFD132M

OMRON

1 Pcs.

Thumbnail 3h Dslr 30mm Flat PNP Light Photoelectric sensor, diffuse, 30mm, DC, 3-wire, PNP, light-on, flat, 2m cable (requires E39-L119 bracket)

Automation > Diffuse reflective photoelectric sensor
E3T

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Manufactured by Omron, this flat thumbnail photoelectric sensor carries the part number E3T-FD13 2M and is engineered for tight spaces where standard sensors cannot fit. It is commonly deployed in electronics assembly and small-part handling equipment.

Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Degree of protection (IP) (EF005474): IP67
  • Material of optical surface (EF004134): Plastic
  • Housing material (EF001596): Plastic
  • Operation agent-safety class (EF003982): Safety class 0
  • Voltage type (EF000187): DC
  • Construction type housing (EF004008): Cuboid
  • Sensing mode (EF007503): Light switching
  • Type of electric connection (EF003961): Cable
  • Type of light (EF004029): Polarity free red light
  • Material of cable sheath (EF004136): Polyvinyl chloride (PVC)
  • Type of switching output (EF003962): PNP
  • With communication interface RS-485 (EF007314): No
  • With communication interface SSD (EF007315): No
  • With communication interface SSI (EF007316): No
  • Analogue output 0 mA ... 20 mA (EF006808): No
  • With communication interface RS-232 (EF007312): No

More info

▲
ShapeCuboid, M2 mountingSensing methodDiffuse reflectiveSensing distance30 mmSensing distance (min.)5 mmSetting methodFixedConnection methodCableCable length2 mOutput typePNPOperation modeLight-ONResponse time1 msMaterial housingPBTThread sizeOtherProduct Width (unpacked)12 mmProduct Height (unpacked)24 mmProduct Depth (unpacked)3.5 mmType of lightPolarity free red lightPower supply voltage12-24 VDegree of protection (IP)IP67

Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
