View larger
Images are for illustrative purposes only. Please refer to data sheet for details
M22N-BC-TRA-RE A2260110B 664398 OMRON M22N flush marker indicator, RED, RED LED 200/240 VAC
M22N-BC-TRA-RE
A2260110B
M22NBCTRARE
OMRON
10 Pcs.
Indicator M22N flush rotulable, RED, RED LED, 200/240 VAC
Indicator M22N flat etched, cap color red, LED red, LED voltage 200-240 VAC
Automation > Indicator light complete
Special
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲Specifications
| Application | Indicator |
| Size | 22 mm |
| Shape | Round |
| Profile | Flat etched |
| Indicator color | Red |
| LED lamp color | Red |
| Rated operating voltage Ue | 200-240 V |
| Voltage type | AC |
| Terminal | Screw |
| Degree of protection (IP) | IP66 |
| Feature Name | Feature Value |
|---|---|
| Voltage type (EF000187) | AC |
| Colour lens (EF000207) | Red |
| Degree of protection (NEMA) (EF011959) | 4X |
| Degree of protection (IP) (EF005474) | IP66 |
| Construction type lens (EF006253) | Round |
| Type of electric connection (EF003961) | Screw connection |
| Type of lamp socket (EF008229) | LED |
| Type of lens (EF008343) | Flat |
| With front ring (EF006014) | No |
| With light source (EF005905) | Yes |
| Hole diameter (EF000079) | 22.3 mm |
| Number of indicator lights (EF001965) | 1 |
| Rated operating voltage Ue (EF002418) | 200 V |
