OMRON D4N-4B72 D4N-4B72 D4N 0252F D4N4B72 OMRON Plastic 2NC Slow-Articulated Vertical M20 View larger
Images are for illustrative purposes only. Please refer to data sheet for details

D4N-4B72 D4N 0252F D4N4B72 OMRON Plastic 2NC Slow-Articulated Vertical M20

D4N-4B72

D4N 0252F

D4N4B72

OMRON

1 Pcs.

Plastic 2NC Slow-Articulated Vertical M20 Plastic 2NC Slow Vertical Articulated M20 Safety Limit switch, D4N, M20 (1 conduit), 2NC (slow-action), one-way roller arm lever (vertical)

Automation > End switch
D4N

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

An Omron D4N-4B72 plastic 2NC slow-articulated vertical M20 limit switch is deployed in industrial machinery to monitor physical positioning, track travel limits, and interlock moving guards. These electromechanical sensors translate mechanical contact from moving parts into electrical signals for control and safety monitoring circuits. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Construction type housing (EF004008): Cuboid
  • Degree of protection (IP) (EF005474): IP67
  • Alignment of the control element (EF008793): Roller cam straight
  • Type of control element (EF006976): Roller cam
  • Type of electric connection (EF003961): Cable entry metrical
  • Switching function (EF000189): Slow-action switch
  • Housing material (EF001596): Plastic
  • Switching function latching (EF007447): No
  • With status indication (EF001602): No
  • Suitable for safety functions (EF001597): Yes
  • Forced opening (EF006694): Yes
  • Output electronic (EF006987): No
  • Number of contacts as change-over contact (EF008257): 0
  • Number of contacts as normally open contact (EF008256): 0
  • Rated operation current Ie at AC-15, 230 V (EF001385): 3 A
  • Rated operation current Ie at DC-13, 125 V (EF007085): 0.55 A

More info

▲
  • Direct opening mechanism and approval by notified body
  • Rugged plastic housing with double insulation
  • Wide range of actuators
  • M12 connectors or terminal block with M20 conduit
