Lever DPDT Solder Basic switch, hinge lever, 10 A, DPDT, screw terminals

Automation > End switch
Other

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

An Omron lever switch, part number DZ-10GW-1B, is a precision-engineered electrical component utilized in control panels and mechanical actuators to manage complex circuit switching pathways. Such devices provide reliable physical actuation for demanding automation tasks requiring multi-pole contact configurations. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Construction type housing (EF004008): Cuboid
  • Housing material (EF001596): Plastic
  • With status indication (EF001602): No
  • Suitable for safety functions (EF001597): No
  • Forced opening (EF006694): No
  • Output electronic (EF006987): No
  • Number of contacts as change-over contact (EF008257): 2
  • Number of contacts as normally open contact (EF008256): 0
  • Rated operation current Ie at AC-15, 230 V (EF001385): 10 A
  • Rated operation current Ie at DC-13, 125 V (EF007085): 0.5 A
  • Number of safety auxiliary contacts (EF006940): 0
  • Rated operation current Ie at DC-13, 230 V (EF001386): 0.25 A
  • Number of contacts as normally closed contact (EF008255): 0
  • Rated operation current Ie at AC-15, 125 V (EF007082): 10 A
  • Width sensor (EF007094): 75.4 mm
  • Height of sensor (EF007283): 27.9 mm
