OMRON D4N-1231 D4N-1231 D4N 0096E D4N1231 OMRON Plastic 2NC Sudden Stroke plane PG13,5 View larger
Images are for illustrative purposes only. Please refer to data sheet for details

D4N-1231 D4N 0096E D4N1231 OMRON Plastic 2NC Sudden Stroke plane PG13,5

D4N-1231

D4N 0096E

D4N1231

OMRON

1 Pcs.

Plastic 2NC Sudden Stroke plane PG13,5 Plastic 2NC Brusca Flat Embolo PG13.5 Limit switch, Top plunger, 2NC (snap-action), 2NC (snap-action), Pg13.5 (1-conduit)

Automation > End switch
D4N

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

D4N-1231 D4N 0096E D4N1231 OMRON Plastic 2NC Sudden Stroke plane PG13,5 operates as a safety limit switch designed to monitor machine positioning and guard closures in industrial automation applications. This component provides rapid contact interruption to safeguard automated processes.

Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Construction type housing (EF004008): Cuboid
  • Degree of protection (IP) (EF005474): IP67
  • Type of control element (EF006976): Plunger
  • Type of electric connection (EF003961): Cable entry PG
  • Switching function (EF000189): Quick-break switch
  • Housing material (EF001596): Plastic
  • Switching function latching (EF007447): No
  • With status indication (EF001602): No
  • Suitable for safety functions (EF001597): Yes
  • Forced opening (EF006694): Yes
  • Output electronic (EF006987): No
  • Number of contacts as change-over contact (EF008257): 0
  • Number of contacts as normally open contact (EF008256): 0
  • Rated operation current Ie at AC-15, 230 V (EF001385): 3 A
  • Rated operation current Ie at DC-13, 125 V (EF007085): 0.55 A
  • Number of safety auxiliary contacts (EF006940): 0

More info

▲
  • Direct opening mechanism and approval by notified body
  • Rugged plastic housing with double insulation
  • Wide range of actuators
  • M12 connectors or terminal block with M20 conduit
