OMRON D4N-1162 D4N-1162 D4N 0049C D4N1162 OMRON Plastic 1NC/1NO Sharp Articu. horizontal PG13,5 View larger
Images are for illustrative purposes only. Please refer to data sheet for details

D4N-1162 D4N 0049C D4N1162 OMRON Plastic 1NC/1NO Sharp Articu. horizontal PG13,5

D4N-1162

D4N 0049C

D4N1162

OMRON

1 Pcs.

Plastic 1NC/1NO Sharp Articu. horizontal PG13,5 Limit switch, One-way roller arm lever (horizontal), 1NC/1NO (snap-action), 1NC/1NO (snap-action), Pg13.5 (1-conduit)

Automation > End switch
D4N

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Plastic 1NC/1NO sharp articu. horizontal Omron D4N-1162 components function as safety position switches installed on industrial enclosures and moving apparatus to monitor physical access and operational boundaries. They reliably interrupt control circuits to protect operators and equipment during routine automation tasks.

Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Construction type housing (EF004008): Cuboid
  • Degree of protection (IP) (EF005474): IP67
  • Alignment of the control element (EF008793): Roller cam straight
  • Type of control element (EF006976): Roller cam
  • Type of electric connection (EF003961): Cable entry PG
  • Switching function (EF000189): Quick-break switch
  • Housing material (EF001596): Plastic
  • Switching function latching (EF007447): No
  • With status indication (EF001602): No
  • Suitable for safety functions (EF001597): Yes
  • Forced opening (EF006694): Yes
  • Output electronic (EF006987): No
  • Number of contacts as change-over contact (EF008257): 0
  • Number of contacts as normally open contact (EF008256): 1
  • Rated operation current Ie at AC-15, 230 V (EF001385): 3 A
  • Rated operation current Ie at DC-13, 125 V (EF007085): 0.55 A

More info

▲
Material housingPlasticActuator typeOne-way roller arm leverActuator detailHorizontalConnection methodTerminal blockConduit sizePG13.5Cable entry directionBottomNumber of contacts, normally-open1Number of contacts, normally-closed1Make before breakSwitch actionSnap action
