OMRON D4F-302-1R D4F-302-1R D4F 0007A D4F3021R OMRON Metal IP67 2NC/2NA Plunger Roller plunger 1m horiz. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

D4F-302-1R D4F 0007A D4F3021R OMRON Metal IP67 2NC/2NA Plunger Roller plunger 1m horiz.

D4F-302-1R

D4F 0007A

D4F3021R

OMRON

1 Pcs.

Metal IP67 2NC/2NA Plunger Roller plunger 1m horiz. Small Safety Limit Switch, 2NC/2NO slow-action, roller plunger, 1 m cable, horizontal cable exit

Automation > End switch
Others

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

The Omron D4F-302-1R is a compact metal position switch designed for safety-related monitoring tasks on industrial automation machinery. Small safety switches provide reliable contact actuation for protective guards, doors, and moving mechanisms where space is restricted. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Construction type housing (EF004008): Cuboid
  • Degree of protection (IP) (EF005474): IP67
  • Alignment of the control element (EF008793): Roller cam straight
  • Type of control element (EF006976): Plunger
  • Type of electric connection (EF003961): With cable preassembled
  • Switching function (EF000189): Slow-action switch
  • Housing material (EF001596): Metal
  • Switching function latching (EF007447): No
  • With status indication (EF001602): No
  • Suitable for safety functions (EF001597): Yes
  • Forced opening (EF006694): Yes
  • Output electronic (EF006987): No
  • Number of contacts as change-over contact (EF008257): 0
  • Number of contacts as normally open contact (EF008256): 2
  • Rated operation current Ie at AC-15, 230 V (EF001385): 0.75 A
  • Rated operation current Ie at DC-13, 125 V (EF007085): 0.55 A

More info

▲
  • Slim-size housing
  • Direct opening mechanism
  • Roller or plunger actuators
  • Pre-wired versions
