OMRON KM20-CTF-200A KM20-CTF-200A KM203006M KM20CTF200A OMRON CT 200A clip-Type Cable 24mm max View larger
Images are for illustrative purposes only. Please refer to data sheet for details

KM20-CTF-200A KM203006M KM20CTF200A OMRON CT 200A clip-Type Cable 24mm max

KM20-CTF-200A

KM203006M

KM20CTF200A

OMRON

1 Pcs.

CT 200A clip-Type Cable 24mm max Current transformer, field installation, 200 A, for cable dia. 24 mm max

Automation > Current transformer
Power monitor

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

KM20-CTF-200A manufactured by Omron is a clip-type through-feed current converter designed for non-invasive cable monitoring and energy metering systems.

Pricing, availability, and lead time are confirmed per enquiry through an RFQ.

  • Model (EF000010): Through-feed current converter
  • Secondary connection (EF021093): Screw connection
  • Overcurrent limiting factor (EF007511): FS 5
  • Calibrated (EF008836): No
  • With copper rail (EF007380): No
  • With contact protection (EF008186): No
  • Snap mounting (EF007462): Yes
  • Rated primary current (EF007405): 200 A
  • Opening diameter (EF005153): 24 mm
  • Number of primary inputs (EF006947): 1
  • Rated secondary current (EF007471): 0.0667 A

Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
