OMRON J7TC-01-6 J7TC-01-6 J7TC5015E J7TC016 OMRON Thermal Overload Relay, Push-In and Plus Terminals, Current setting range .. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

J7TC-01-6 J7TC5015E J7TC016 OMRON Thermal Overload Relay, Push-In and Plus Terminals, Current setting range ..

J7TC-01-6

J7TC5015E

J7TC016

OMRON

1 Pcs.

Thermal Overload Relay, Push-In and Plus Terminals, Current setting range thermal overload release 4 - 6, H×W×D 79.5 x 45 x 55.5 mm

Automation > Thermal overload relay
J7TK Thermal overload relays

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲
Auxiliary Contacts NO1Auxiliary Contacts NC1Setting range Star-delta [A]4-6 ASetting range D.O.L. (A)4-6 ATerminal typePush-in PlusProduct Width (unpacked)45 mmProduct Height (unpacked)97.5 mmProduct Depth (unpacked)55.5 mm
ETIM for 690039 Low-voltage industrial controls and switchgear (EC000106)
Feature Name Feature Value
Mounting method (EF000003) Direct attachment
Type of electrical connection of main circuit (EF006819) Other
Number of auxiliary contacts as normally closed contact (EF001377) 1
Number of auxiliary contacts as normally open contact (EF001376) 1
Adjustable current range (EF008211) 4 A
