D4F-202-5D D4F 0046B D4F2025D OMRON Metal IP67 2NC Plunger Roller plunger 5m vert.
D4F-202-5D
D4F 0046B
D4F2025D
OMRON
1 Pcs.
Automation > End switch
Others
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
An Omron D4F-202-5D limit switch serves as a high-precision sensor used in automated systems to detect the precise position of mechanical parts, doors, or safety barriers. It ensures dependable signal transmission and safety interlock compliance.
Specific pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Construction type housing (EF004008): Cuboid
- Degree of protection (IP) (EF005474): IP67
- Alignment of the control element (EF008793): Roller cam straight
- Type of control element (EF006976): Plunger
- Type of electric connection (EF003961): With cable preassembled
- Switching function (EF000189): Slow-action switch
- Housing material (EF001596): Metal
- Switching function latching (EF007447): No
- With status indication (EF001602): No
- Suitable for safety functions (EF001597): Yes
- Forced opening (EF006694): Yes
- Output electronic (EF006987): No
- Number of contacts as change-over contact (EF008257): 0
- Number of contacts as normally open contact (EF008256): 0
- Rated operation current Ie at AC-15, 230 V (EF001385): 0.75 A
- Rated operation current Ie at DC-13, 125 V (EF007085): 0.55 A
More info
▲- Slim-size housing
- Direct opening mechanism
- Roller or plunger actuators
- Pre-wired versions
