OMRON H3DS-XLC H3DS-XLC H3DS8007H H3DSXLCBYOKXOMI OMRON 17.5 mm DIN Delay ON a fast Connection View larger
Images are for illustrative purposes only. Please refer to data sheet for details

H3DS-XLC H3DS8007H H3DSXLCBYOKXOMI OMRON 17.5 mm DIN Delay ON a fast Connection

H3DS-XLC

H3DS8007H

H3DSXLCBYOKXOMI

OMRON

1 Pcs.

17.5 mm DIN Delay ON a fast Connection 17.5mm DIN Delay ON Quick Connect Timer, DIN rail mounting, 17.5 mm, 24-230 VAC/VDC, on-delay, 0.1 s-120 h, SCR output 0.7 A, 2-wire in-line load connection, lockable settings, screwle

Automation > Timer relay
H3DS

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲
Features

DIN-rail mounted, standard 17.5mm-width solid state timer range

This broad range of timers includes many functionalities and has a wide AC/DC power supply range. Models with screwless clamp connection available.

  • 17.5mm width, modular 45mm
  • DIN-rail mounting
  • 24-48VDC and 24-230VAC
  • 0.1 s to 120 h, 7 ranges

Ordering information

Type

Supply voltage

Control output

Time setting range

Operating modes

Order code

Screw
terminal type

Screw-less
clamp type

Multi-functional timer

24 to 230 VAC
(50/60 Hz)/
24 to 48 VDC

SPDT

0.1 s to120 h

ON-delay, flicker OFF start, flicker ON start,
signal ON/OFF-delay, signal OFF-delay,
interval, one-shot

H3DS-ML

H3DS-MLC

Standard timer

ON-delay, flicker ON start, interval, one­shot

H3DS-SL

H3DS-SLC

Single function timer

ON-delay

H3DS-AL

H3DS-ALC

Twin timer

Relay SPDT

0.1 s to 12 h

Flicker OFF start, flicker ON start

H3DS-FL

H3DS-FLC

Star-delta timer

2× Relay SPST-NO

1 s to 120 s

Star-delta

H3DS-GL

H3DS-GLC

Two-wired timer

24 to 230 VAC/VDC
(50/60 Hz)

SCR output

0.1 s to 120 h

ON-delay

H3DS-XL

H3DS-XLC

Specifications

Terminal block

Screw terminal type: Clamps two 2.5 mm2 max. bar terminals without sleeves

Screw-less clamp type: Clamps two 1.5 mm2 max. bar terminals without sleeves

Mounting method

DIN-rail mounting

Operating voltage range

85 to 110% of rated supply voltage

Power reset

Minimum power-off time: 0.1 s, 0.5 s for H3DS-G

Reset voltage

2.4 VAC/VDC max., 1.0 VAC/VDC max. for H3DS-X

Voltage input

Max. permissible capacitance between input lines (terminals B1 and A2): 2,000 pF

Load connectable in parallel with inputs (terminals B1 and A1)

H-level: 20.4 to 253 VAC/20.4 to 52.8 VDC

L-level: 0 to 2.4 VAC/VDC

Control output

Contact output: 5 A at 250 VAC with resistive load (cosφ = 1)

5 A at 30 VDC with resistive load (cosφ = 1)

Ambient temperature

Operating: -10 to 55°C (with no icing)

Storage: -25 to 65°C (with no icing)

Accuracy of operating time

±1% max. of FS (±1% ±10 ms max. at 1.2 s range)

Setting error

±10% ±50 ms max. of FS

Influence of voltage

±0.7% max. of FS (±0.7% ±10 ms max. at 1.2 s range)

Influence of temperature

±5% max. of FS (±5% ±10 ms max. at 1.2 s range)

Life expectancy (not H3DS-X)

Mechanical: 10 million operations min. (under no load at 1,800 operations/h)

Electrical: 100,000 operations min. (5 A at 250 VAC, resistive load at 360 operations/h)

Size in mm(HxWxD)

80x17.5x73

ETIM for 670942 Relays (EC001439)
Feature Name Feature Value
Relay technology category according to IEC 61810-7 (EF016748) RT I
Material of contact insert (EF008521) Other
Degree of protection (IP) (EF005474) IP30
Voltage type (operating voltage) (EF005294) AC/DC
Material of contact surface (EF004020) Other
Voltage type for actuating (EF008242) AC/DC
Type of electric connection (EF003961) Spring clamp connection
Material contact (EF007544) Other
Function delay on de-energization (EF003401) Yes
Suitable as remote control (EF003362) Yes
Outputs, reversible delayed/undelayed (EF006988) No
Function pulse shaping (EF003403) No
Suitable for DIN rail (top hat rail) mounting (EF007250) Yes
Complete with socket (EF003359) No
Function star-delta (EF003380) No
Function floating contact on energization (EF003378) Yes
Clock function, starting with pause, variable (EF003365) No
Function flashing, starting with pulse, fixed time (EF003364) No
Function delay-on energization (EF003374) Yes
With semiconductor output (EF003373) Yes
Function floating contact on de-energization (EF003402) No
Function flashing, starting with pause, fixed time (EF003363) No
Suitable for front mounting (EF020288) No
Clock function, starting with pulse, variable (EF003366) No
Pluggable on auxiliary contact block (EF006952) No
Remote operation possible (EF003361) No
Number of outputs, delayed, normally open contact (EF006839) 0
Number of outputs, undelayed, normally open contact (EF006836) 0
Number of outputs, delayed, change-over contact (EF006840) 1
Number of outputs, delayed, normally closed contact (EF006838) 0
Number of outputs, undelayed, change-over contact (EF006837) 0
Width (EF000008) 17.5 mm
Number of outputs, undelayed, normally closed contact (EF006835) 0
Height (EF000040) 79 mm
Depth (EF000049) 100 mm
Nominal current (EF000001) 5 A
Rated control supply voltage AC 60 Hz (EF003979) 24 V
Operating voltage DC (EF008208) 0 V
Rated control supply voltage AC 50 Hz (EF003978) 24 V
Time range (EF003384) 0.1 s
Rated control supply voltage DC (EF003980) 24 V
Operating voltage AC 50 Hz (EF008206) 0 V
Operating voltage AC 60 Hz (EF008207) 0 V
