OMRON G3H-203SN-VD 5-24VDC G3H-203SN-VD 5-24VDC G3H 1045M G3H203SNVDDC524 OMRON Relay solid state fototriac to base View larger
Images are for illustrative purposes only. Please refer to data sheet for details

G3H-203SN-VD 5-24VDC G3H 1045M G3H203SNVDDC524 OMRON Relay solid state fototriac to base

G3H-203SN-VD 5-24VDC

G3H 1045M

G3H203SNVDDC524

OMRON

10 Pcs.

Relay solid state fototriac to base Solid state relay, 200VAC, 3A, plug-in, LED indicator

Automation > Solid state relay
Other

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Omron G3H-203SN-VD 5-24VDC is a phototriac-based solid-state relay designed for secure base mounting in industrial control and instrumentation systems. Socket-compatible interface relays allow operators to isolate control circuitry from heavy load circuits while ensuring fast, bounce-free signal transmission. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Switching at zero-crossing (EF011956): Yes
  • Rated operation current Ie at AC-1 (EF006069): 3 A
  • Number of phases (EF000351): 1
  • Rated control supply voltage DC (EF003980): 5 V

More info

▲
ApplicationInterfaceNumber of phases1Mounting methodWith plug-in socketTerminal typePlug-inComplete with socketLED indicatorRated operational voltage, AC100-240 VOperating voltage range, AC75-264 VRated operation current Ie at AC-13 ASupply voltage DC5-24 VControl current max.15 mAMust operate voltage max.4 VMust release voltage min.1 VMaximum operating temperature80 °CMinimum operating temperature-30 °CIsolationPhotocouplerSwitching at zero-crossing

Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
