OMRON E3X-NA6 E3X-NA6 E3X 7005F E3XNA6OMS OMRON Manual dc Connector M/S NPN Timing GIGA RAY Led View larger
Images are for illustrative purposes only. Please refer to data sheet for details

E3X-NA6 E3X 7005F E3XNA6OMS OMRON Manual dc Connector M/S NPN Timing GIGA RAY Led

E3X-NA6

E3X 7005F

E3XNA6OMS

OMRON

1 Pcs.

Manual dc Connector M/S NPN Timing GIGA RAY Led Amplifier with potentiometer, IP50, NPN output, connector

Automation > Optical fibre sensor / optical fibre amplifier
E3X

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Industrial control systems incorporate units such as the Omron E3X-NA6 manual DC connector fiber amplifier to process optical signals for precise automated object detection. This device interprets light intensity changes from linked fiber cables to trigger switching actions in high-speed assembly processes.

Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Voltage type (EF000187): DC
  • Construction type housing (EF004008): Cuboid
  • Degree of protection (IP) (EF005474): IP50
  • Setting procedure (EF003994): Manual adjustment
  • Indication (EF000350): Bar graph
  • Type of switch function (EF003963): Programmable/configurable
  • Type of electric connection (EF003961): Plug-in connection
  • Material fibre optics core (EF004137): Plastic
  • Housing material (EF001596): Plastic
  • Type of light (EF004029): Polarity free red light
  • Type of switching output (EF003962): NPN
  • Operation agent-safety class (EF003982): Safety class 0
  • Analogue output -10 V ... +10 V (EF006809): No
  • Analogue output 0 V ... 10 V (EF006807): No
  • Analogue output 0 mA ... 20 mA (EF006808): No
  • With blanking function (EF003968): No

More info

▲
ShapeCuboid, rail mountingSensing methodAmplifierSetting methodManual adjustmentConnection methodSystem connectorOutput typeNPNOperation modeDark-ON, Light-ONResponse time0.2 msMaterial housingPBTProduct Width (unpacked)10 mmProduct Height (unpacked)31.5 mmProduct Length (unpacked)64.3 mmType of lightPolarity free red lightPower supply voltage12-24 VFunctionsTimerApplicationObject detectionNumber of channels1Degree of protection (IP)IP50Number of digital outputs1

Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
