OMRON E3X-NA51 2M E3X-NA51 2M E3X 7018H E3XNA512MOMS OMRON Manual cc 3h PNP-Timed. Self-diagnosis

View larger

Images are for illustrative purposes only. Please refer to data sheet for details

E3X-NA51 2M E3X 7018H E3XNA512MOMS OMRON Manual cc 3h PNP-Timed. Self-diagnosis

Name: E3X-NA51 2M E3X 7018H E3XNA512MOMS OMRON Manual cc 3h PNP-Timed. Self-diagnosis
Brand: OMRON
SKU: E3X 7018H

Reference: E3X-NA51 2M

Code: E3X 7018H

Catalog Number: E3XNA512MOMS

Manufacturer: OMRON

Units per package: 1 Pcs.

Description:

Manual cc 3h PNP-Timed. Self-diagnosis Photoelectric sensor, optical fibre amplifier, bar LED display, diagnostic output, DC, 3-wire, PNP, 2m cable

Categories:
Automation > Optical fibre sensor / optical fibre amplifier
E3X

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Guarantee, repair and return.

More info

▲

Features

Digital fiber amplifier with potentiometer adjustment

The E3X-NA is the ideal amplifier for standard fiber applications providing quick & easy potentiometer adjustment and bargraph display.

Easy adjustment with potentiometer
Mutual interference prevention
Enhanced water resistance types

Simple adjustment

Bargraph display with light level, switching status and threshold indicators.

Simple sensitivity adjustment by potentiometer.

Ordering information

Pre-wired

Item	Order code (for pre-wired types with 2 m cable length)
Item	NPN output	PNP output
Standard	E3X-NA11 2M	E3X-NA41 2M
Enhanced water resistance	E3X-NA11V 2M	E3X-NA41V 2M

Connector version

Item	Order code
	NPN output	PNP output
	NPN output	PNP output	Standard (fiber amplifier connector)1	E3X-NA6	E3X-NA8
Enhanced water resistance (M8 4-pin connector)	E3X-NA14V	E3X-NA44V

Fiber amplifier connectors

Type	Comment	Order code
Fiber amplifier connector	2 m PVC cable	E3X-CN21
	30 cm PVC cable with M12 plug connector (4 pin)	E3X-CN21-M1J 0.3M
	30 cm PVC cable with M8 plug connector (4 pin)	E3X-CN21-M3J-2 0.3M

Specifications

Item		Standard	Enhanced water resistance
Output	NPN output	E3X-NA11, E3X-NA6	E3X-NA11V, E3X-NA14V
Output	PNP output	E3X-NA41, E3X-NA8	E3X-NA41V, E3X-NA44V
Light source (wave length)		Red LED (625 nm)
Power supply voltage		12 to 24 VDC±10%, ripple (p-p): 10% max.
Protective circuit		Reverse polarity protection, output short-circuit protection, mutual interference prevention
Response time		Operation or reset: 200 µs max.
Sensitivity setting		8-turn endless adjuster (potentiometer)
Functions		OFF-delay timer: 40 ms (fixed)
Degree of protection		IEC 60529 IP50 (with protective cover attached)	IEC 60529 IP66 (with protective cover attached)

1.Order connector separately.
