G9SA-501 AC/DC24 G9SA6002F G9SA501ACDC24 OMRON Module, Safety, 5PST-NA SPST-NC 24vac/dc
G9SA-501 AC/DC24
G9SA6002F
G9SA501ACDC24
OMRON
1 Pcs.
Automation > Device for monitoring of safety-related circuits
G9SA/B
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
A safety relay module monitors emergency stop circuits and interlocking safety guards, cutting power instantly to prevent injury during machine malfunctions. The Omron G9SA-501 AC/DC24 operates on standard control voltages and is built with robust internal switching contacts for industrial automation applications.
Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- 3PST-NO: SPST-NC
- 100 to 240 VAC 5PST-NO: SPST-NC
- 100 to 240 VAC 15 s: 24 VAC/VDC
- 100 to 240 VAC 30 s: 24 VAC/VDC
- 3PST-NO: SPST-NC
- 15 s: G9SA-EX031-T15
- 30 s: G9SA-EX031-T30
- Power supply voltage: 24 VAC/VDC: 24 VAC, 50/60 Hz, or 24 VDC 100 to 240 VAC: 100 to 240 VAC, 50/60 Hz
- Operating voltage range: 85 to 110% of rated power supply voltage
- Input current: 40 mA max.
- Rated load: 250 VAC, 5 A
- Rated carry current: 5 A
- Operating time: 30 ms max. (not including bounce time)
- Response time 1: 10 ms max. (not including bounce time)
- Durability: Mechanical
- Electrical: 100,000 operations min. (at approx. 1,800 operations/hr)
More info
▲- 45mm-wide housing, expansion units are 17.5mm wide
- Safe OFF-delay timer
- Simple expansion connection
- Certification up to PLe according to EN ISO 13849-1 depending on the application
Specifications & ordering info
Ordering information
Emergency-stop units
Emergency-stop OFF-delay units
Two-hand controller
Expansion unit
The expansion unit connects to a G9SA-301, G9SA-501, G9SA-321, or G9SA-TH301.
Expansion units with OFF-delay outputs
The expansion unit connects to a G9SA-301, G9SA-501, G9SA-321, or G9SA-TH301.
Specifications
Power input
24 VAC/VDC: 24 VAC, 50/60 Hz, or 24 VDC | |||
Inputs
Contacts
Characteristics
Response time1 | ||||
Operating: -25 to 55°C (with no icing or condensation) | ||||
