G9SA-321-T30 AC/DC24 G9SA6005M G9SA321T30ACDC24 OMRON Security module 3PST-NA SPST-NC DPST-NA Temp. OFF 30s ..
G9SA-321-T30 AC/DC24
G9SA6005M
G9SA321T30ACDC24
OMRON
1 Pcs.
Automation > Device for monitoring of safety-related circuits
G9SA/B
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
The Omron G9SA-321-T30 AC/DC24 (G9SA321T30ACDC24) security module provides critical safety interlock and signal evaluation in industrial control systems. Safety modules manage emergency stops and protective door circuits by safely interrupting power to hazardous machine components upon fault detection.
Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- 3PST-NO: SPST-NC
- 100 to 240 VAC 5PST-NO: SPST-NC
- 100 to 240 VAC 15 s: 24 VAC/VDC
- 100 to 240 VAC 30 s: 24 VAC/VDC
- 3PST-NO: SPST-NC
- 15 s: G9SA-EX031-T15
- 30 s: G9SA-EX031-T30
- Power supply voltage: 24 VAC/VDC: 24 VAC, 50/60 Hz, or 24 VDC 100 to 240 VAC: 100 to 240 VAC, 50/60 Hz
- Operating voltage range: 85 to 110% of rated power supply voltage
- Input current: 40 mA max.
- Rated load: 250 VAC, 5 A
- Rated carry current: 5 A
- Operating time: 30 ms max. (not including bounce time)
- Response time 1: 10 ms max. (not including bounce time)
- Durability: Mechanical
- Electrical: 100,000 operations min. (at approx. 1,800 operations/hr)
More info
▲- 45mm-wide housing, expansion units are 17.5mm wide
- Safe OFF-delay timer
- Simple expansion connection
- Certification up to PLe according to EN ISO 13849-1 depending on the application
Specifications & ordering info
Ordering information
Emergency-stop units
Emergency-stop OFF-delay units
Two-hand controller
Expansion unit
The expansion unit connects to a G9SA-301, G9SA-501, G9SA-321, or G9SA-TH301.
Expansion units with OFF-delay outputs
The expansion unit connects to a G9SA-301, G9SA-501, G9SA-321, or G9SA-TH301.
Specifications
Power input
24 VAC/VDC: 24 VAC, 50/60 Hz, or 24 VDC | |||
Inputs
Contacts
Characteristics
Response time1 | ||||
Operating: -25 to 55°C (with no icing or condensation) | ||||
