OMRON GX-JC03 GX-JC03 GX 5030H GXJC03 OMRON Diverter line EtherCAT 3 port View larger
Images are for illustrative purposes only. Please refer to data sheet for details

GX-JC03 GX 5030H GXJC03 OMRON Diverter line EtherCAT 3 port

GX-JC03

GX 5030H

GXJC03

OMRON

1 Pcs.

Diverter line EtherCAT 3 port 3-port EtherCAT Junction module, 24 VDC power supply

Automation > Network switch
Accessories

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Designed as a diverter line EtherCAT 3 port unit, the Omron GX-JC03 facilitates branching and signal distribution within high-speed industrial fieldbus networks. Network couplers and line diverters help organize topologies, simplify physical cabling layouts, and extend communication reach across complex machine setups. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Mounting method (EF000003): DIN rail (top hat rail)
  • Degree of protection (IP) (EF005474): IP20
  • Ethernet (EF003535): Yes
  • Manageable (EF004912): No
  • Layer 3 (EF004884): No
  • Layer 2 (EF004883): No
  • Number of ports 10 Gbps Mini GBIC (EF008850): 0
  • Number of ports 100/1000 Mbps Mini GBIC (EF008849): 0
  • Number of ports 1000 Mbps GBIC (EF004318): 0
  • Number of max. stackable switches (EF003598): 0
  • Number of ports 1000 Mbps Mini GBIC (EF004321): 0
  • Number of ports 10/100 Mbps RJ45 (EF003549): 3
  • Number of ports PoE (EF009715): 3
  • Number of ports 10/100/1000 Mbps RJ45 (EF004316): 0
  • Width (EF000008): 25 mm
  • Number of module slots (EF003597): 0
