A165E-LS-24D-02 A16E7004A A165ELS24D02 OMRON Emergency stop button 16mm DPST-NC LED
A165E-LS-24D-02
A16E7004A
A165ELS24D02
OMRON
5 Pcs.
Automation > Emergency stop complete
Others
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
The A165E-LS-24D-02 A16E7004A A165ELS24D02 OMRON Emergency stop button 16mm DPST-NC LED is a compact illuminated safety switch configured to halt industrial processes and provide visual status feedback. Its space-saving footprint makes it ideal for dense control panels where reliable circuit interruption is required. Pricing, availability, and lead time are confirmed per enquiry through an RFQ.
- LED: 24 VDC
- DPST-NC: A165E-LS-24D-02
- DPST-NC: A165E-S-02
- TPST-NC: A165E-S-03U
- DPST-NC: A165E-LM-24D-02
- DPST-NC: A165E-M-02
- TPST-NC: A165E-M-03U
- Yellow plate: Yellow, 45 dia.
- Panel plug: Round
- 125 VAC: 5 A
More info
▲- Direct opening mechanism with minimum contact separation of 3mm
- Safety lock mechanism prevents misuse
- Short mounting depth
- Modular construction; easy installation using snap-in switch
Specifications & ordering info
Ordering information
Note: The above models have a surface indication of “RESET.” Models with “STOP” indication are also available. For further information, contact your Omron representative.
Accessories (order separately)
Used for covering the panel cutouts for future panel expansion. | |||
Useful for repetitive mounting. Be careful not to tighten excessively. | |||
Specifications
1,000 VAC, 50/60 Hz for 1 min between terminals of same polarity | ||
Operating: -10 to 55°C (with no icing or condensation) | ||
