EE-SX677P EESX2272H EESX677P,1 OMRON Horseshoe 5mm Light/Osc. Select. PNP
EE-SX677P
EESX2272H
EESX677P.1
OMRON
10 Pcs.
Automation > Fork light barrier
Photomicro
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
The Omron EE-SX677P provides dependable optical sensing via a horseshoe-shaped slot configuration for automated machinery and industrial control panels. Slot sensors are widely relied upon to monitor material feeds, detect rotational markers, and establish precise reference points on moving equipment. Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Through-beam with slot: 5 mm (slot width) (Infrared light)
- L-shaped: EE-SX671
- T-shaped, 7 mm: EE-SX672
- Close-mounting: EE-SX673
- Close-mounting: EE-SX674
- T-shaped, 10 mm: EE-SX675
- F-shaped: EE-SX676
- R-shaped: EE-SX677
- Sensing distance: 5 mm (slot width)
- Power supply voltage: 5 to 24 VDC ±10%, ripple (p-p): 10% max.
- Response frequency: 1 kHz min. (3 kHz average)
- Ambient temperature: Operating: -25 to 55°C, Storage: -30 to 80°C
- Degree of protection: IEC60529 IP50
- Material: Case; Lens: Polycarbonate
- Connector with Cable: 2 m
More info
▲Photo microsensor in plastic fork shape housing
For smaller size see the EE-SX95. For larger fork size sensors see the E3Z-G.
- Response frequency up to 1 kHz
- Wide operating voltage range: 5 to 24 VDC
Connector models
Shape1 | Order code2 | |||||
|---|---|---|---|---|---|---|
Connector (4 pin)3 | ||||||
Specifications
Accessories (order separately)
Note:For mechanical limit switches see pageRefer to Mechanical sensors/Limit switches
