> OMRON > Photoelectric sensors > Accessories > EE 1042R
OMRON EE-1010 1M EE-1010 1M EE 1042R EE10101M OMRON Accessory Photomicrosensor EE-SPX 03, cable connector, PVC, 1 m View larger
Images are for illustrative purposes only. Please refer to data sheet for details

EE-1010 1M EE 1042R EE10101M OMRON Accessory Photomicrosensor EE-SPX 03, cable connector, PVC, 1 m

EE-1010 1M

EE 1042R

EE10101M

OMRON

1 Pcs.

Accessory Photomicrosensor EE-SPX_03, cable connector, PVC, 1 m

Automation > Sensor-actuator patch cord
Accessories

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲
Features

Photo microsensor in plastic fork shape housing

For smaller size see the EE-SX95. For larger fork size sensors see the E3Z-G.

  • Response frequency up to 1 kHz
  • Wide operating voltage range: 5 to 24 VDC

Ordering information

Connector models

Sensor type

Sensing distance

Connection method

Operation Mode

Shape1

Order code2

NPN output

PNP output

Through-beam with slot

5 mm
(slot width)
(Infrared light)

Connector (4 pin)3

Dark-ON/Light-ON
(selectable)


EE-SX670

EE-SX670P


EE-SX671

EE-SX671P

T-shaped, 7 mmEE-SX47_67_rev01-4.png

EE-SX672

EE-SX672P


EE-SX673

EE-SX673P


EE-SX674

EE-SX674P

T-shaped, 10 mmEE-SX47_67_rev01-7.png

EE-SX675

EE-SX675P


EE-SX676

EE-SX676P


EE-SX677

EESX-677P

Specifications

Item

Through-beam

Standard

L-shaped

T-shaped,
slot center: 7 mm

Close-mounting

T-shaped,
slot center: 10 mm

F-shaped

R-shaped

NPN

EE-SX670

EE-SX671

EE-SX672

EE-SX673

EE-SX674

EE-SX675

EE-SX676

EE-SX677

PNP

EE-SX670P

EE-SX671P

EE-SX672P

EE-SX673P

EE-SX674P

EE-SX675P

EE-SX676P

EE-SX677P

Sensing distance

5 mm (slot width)

Power supply voltage

5 to 24 VDC ±10%, ripple (p-p): 10% max.

Response frequency

1 kHz min. (3 kHz average)

Ambient temperature

Operating: -25 to 55°C, Storage: -30 to 80°C

Degree of protection

IEC60529 IP50

Material

Case

PBT (polybutylene terephthalate)

Lens

Polycarbonate

Accessories (order separately)

Type

Cable length

Material

Order code

Connector with Cable

2 m

PVC

EE-1010 2M

Connector with Robot Cable

2 m

PVC

EE-1010R 2M

Note:For mechanical limit switches see pageRefer to Mechanical sensors/Limit switches


1.For shape dimensions refer to datasheet on www.industrial.omron.eu

2.For pre-wired models with 1 m cable add '-WR' to order reference (e.g. EE-SX670-WR)

3.Order connector separately from accessories
