View larger
Images are for illustrative purposes only. Please refer to data sheet for details
E5AN-HTAA3BFMD-500 24VAC/DC E5AN1307F E5ANHTAA3BFMD500ACDC24 OMRON Control advanced temperature , universal ..
E5AN-HTAA3BFMD-500 24VAC/DC
E5AN1307F
E5ANHTAA3BFMD500ACDC24
OMRON
1 Pcs.
Control advanced temperature , universal input, panel, 96x96mm, display, PV/SV/MV .
Advanced Temperature Control, Universal Input, Panel, 96x96mm, PV/SV/MV display.
E5_N-HT series adv. Ramp/Soak temp. contr., 1/4DIN (96 x 96mm), uni. input (TC, RTD, Linear), event inputs, transfer output, remote SP, 24 VAC/DC
Automation > Temperature monitoring relay
E5AN-H
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲| Feature Name | Feature Value |
|---|---|
| Voltage type (operating voltage) (EF005294) | AC/DC |
| Type of electric connection (EF003961) | Screw connection |
| Voltage type (supply voltage) (EF002991) | AC/DC |
| Error registration possible (EF003423) | No |
| External reset possible (EF003426) | No |
| With detachable clamps (EF003340) | No |
| Number of contacts as change-over contact (EF008257) | 0 |
| Number of contacts as normally open contact (EF008256) | 3 |
| Width (EF000008) | 96 mm |
| Number of contacts as normally closed contact (EF008255) | 0 |
| Number of measuring circuits (EF003425) | 1 |
| Height (EF000040) | 96 mm |
| Depth (EF000049) | 79.2 mm |
| Supply voltage AC 50 Hz (EF007532) | 20.4 V |
| Temperature measuring range (EF009788) | -200 °C |
| Supply voltage AC 60 Hz (EF007533) | 20.4 V |
| Supply voltage DC (EF007534) | 20.4 V |
