OMRON E32-L25T 2M E32-L25T 2M E32 1449B E32L25T2M OMRON Direct reflection limited View larger
Images are for illustrative purposes only. Please refer to data sheet for details

E32-L25T 2M E32 1449B E32L25T2M OMRON Direct reflection limited

E32-L25T 2M

E32 1449B

E32L25T2M

OMRON

1 Pcs.

Direct reflection limited Limited Direct Reflection Fiber optic sensor head, limited reflective, liquid level detection, tube mounting 8 to 10 mm diameter, R10 fiber, 2 m cable

Automation > Optical fibre sensor / optical fibre amplifier
E32

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Omron E32-L25T 2M is a direct reflection limited fiber optic unit intended for targeted surface detection and part verification in automated machinery. Diffuse reflective fiber optic setups allow engineers to detect objects without requiring separate receiver units on the opposite side.

Pricing, availability, and lead time are confirmed per enquiry through an RFQ.

  • Voltage type (EF000187): DC
  • Construction type housing (EF004008): Special construction
  • Degree of protection (IP) (EF005474): IP50
  • Material fibre optics core (EF004137): Plastic
  • Housing material (EF001596): Plastic
  • Operation agent-safety class (EF003982): Safety class 0
  • Analogue output -10 V ... +10 V (EF006809): No
  • Analogue output 0 V ... 10 V (EF006807): No
  • Analogue output 0 mA ... 20 mA (EF006808): No
  • With blanking function (EF003968): No
  • Analogue output 4 mA ... 20 mA (EF006810): No
  • With time function (EF003582): No
  • Ambient temperature (EF002386): -40 °C

More info

▲
Sensing methodLimited reflectiveShapeSquareApplicationLiquid level detectionTemperature range-40-70 °CCable length2 mBending radius10 mmFree cutMaterial corePlasticDegree of protection (IP)IP50Material sheathPolyethylene
