> OMRON > Control Systems > CS1 > CS1D0008F
OMRON CS1D-PD024 CS1D-PD024 CS1D0008F CS1DPD024 OMRON Power supply 24 Vdc for CS1 Duplex View larger
Images are for illustrative purposes only. Please refer to data sheet for details

CS1D-PD024 CS1D0008F CS1DPD024 OMRON Power supply 24 Vdc for CS1 Duplex

CS1D-PD024

CS1D0008F

CS1DPD024

OMRON

1 Pcs.

Power supply 24 Vdc for CS1 Duplex Power supply unit for duplex system, 24 VDC, CS1 duplex/simplex backplanes only

Automation > PLC system power supply
CS1

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Omron CS1D-PD024 is a power supply unit engineered specifically for high-availability duplex controller systems and redundant rack configurations. Dual-compatible power modules ensure uninterrupted electrical continuity for mission-critical automation systems where system downtime must be strictly avoided.

Pricing, availability, and lead time are confirmed per enquiry through an RFQ.

  • 19.2 to 28.8 VDC: 40 W max.
  • 4.3 A: 0.56 A
  • 55 VA max.: 5.3 A
  • Power supply for dual-redundant system: CS1D-PD025
  • 85 to 264 VAC 50/60 Hz: 120 VA max.
  • Service output 24 VDC, 0.8 A: C200HW-PA204S
  • Run status output (SPST relay): C200HW-PA204R
  • 180 VA max.: 9.0 A
  • 150 VA max.: 7.0 A
  • CPU backplane: 2
  • CPU backplane: 3
  • CPU backplane: 5
  • CPU backplane: 8
  • CPU backplane: 10
  • Expansion backplane: 3
  • Expansion backplane: 5

More info

▲

Specifications & ordering info

Ordering information

Power supplies

Input range

Power
consumption

Output capacity 5 VDC

Output capacity 26 VDC

Max. output
power

Extra functions

Order code

19.2 to 28.8 VDC

40 W max.

6.6 A

0.62 A

30 W

-

C200HW-PD024

4.3 A

0.56 A

28 W

Power supply for dual-redundant system

CS1D-PD024

55 VA max.

5.3 A

1.3 A

40 W

-

C200HW-PD025

Power supply for dual-redundant system

CS1D-PD025

85 to 264 VAC
50/60 Hz

120 VA max.

4.6 A

0.62 A

30 W

Maintenance status display

C200HW-PA204C

85 to 132 VAC,
170 to 264 VAC,
50/60 Hz

-

C200HW-PA204

Service output 24 VDC, 0.8 A

C200HW-PA204S

Run status output (SPST relay)

C200HW-PA204R

180 VA max.

9.0 A

1.3 A

45 W

Run status output (SPST relay)

C200HW-PA209R

150 VA max.

7.0 A

1.3 A

35 W

Power supply for dual-redundant system

CS1D-PA207R

Backplanes

Type

Slots

Expansion connector

Width

Special functions

Order code

CPU backplane

2

No

200 mm

-

CS1W-BC023

CPU backplane

3

Yes

260 mm

-

CS1W-BC033

CPU backplane

5

Yes

330 mm

-

CS1W-BC053

CPU backplane

8

Yes

435 mm

-

CS1W-BC083

CPU backplane

10

Yes

505 mm

-

CS1W-BC103

Expansion backplane

3

Yes

260 mm

-

CS1W-BI033

Expansion backplane

5

Yes

330 mm

-

CS1W-BI053

Expansion backplane

8

Yes

435 mm

-

CS1W-BI083

Expansion backplane

10

Yes

505 mm

-

CS1W-BI103

CPU backplane

5

Yes

505 mm

For Duplex CPU + Power supplies

CS1D-BC052

CPU backplane

8

Yes

505 mm

For Duplex Power supplies

CS1D-BC082S

Expansion backplane

9

Yes

505 mm

For Duplex Power supplies

CS1D-BI092

Accessories

Type

Remarks

Order code

I/O Expansion cable to connect CS1 CPU backplane or
Expansion backplane to next
Expansion backplane.

0.3 m

CS1W-CN313

0.7 m

CS1W-CN713

2.0 m

CS1W-CN223

3.0 m

CS1W-CN323

5.0 m

CS1W-CN523

10.0 m

CS1W-CN133

12.0 m

CS1W-CN133-B2
