OMRON D4NS-4FF D4NS-4FF D4NS0024G D4NS4FF OMRON Plastic 2NC/1NO MBB M20 View larger
Images are for illustrative purposes only. Please refer to data sheet for details

D4NS-4FF D4NS0024G D4NS4FF OMRON Plastic 2NC/1NO MBB M20

D4NS-4FF

D4NS0024G

D4NS4FF

OMRON

1 Pcs.

Plastic 2NC/1NO MBB M20 Safety-door switch, D4NS, M20 (1-conduit), 2NC/1NO (MBB contact)

Automation > Position switch with separate actuator
D4DL/DS/DH/DR/GL/NL/NH/NS

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Operating as an Omron D4NS-4FF Plastic 2NC/1NO MBB M20 safety position switch, this hardware protects personnel by monitoring physical barriers and machine enclosures. Mechanical limit and position switches are essential components in automated manufacturing cells to verify that safety gates remain securely closed during hazardous operations. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Construction type housing (EF004008): Cuboid
  • Type of switching contact (EF003591): Slow-action switch
  • Degree of protection (IP) (EF005474): IP67
  • Type of electric connection (EF003961): Cable entry metrical
  • With status indication (EF001602): No
  • Suitable for safety functions (EF001597): Yes
  • Forced opening (EF006694): No
  • Number of contacts as change-over contact (EF008257): 0
  • Number of contacts as normally open contact (EF008256): 1
  • Rated operation current Ie at AC-15, 230 V (EF001385): 3 A
  • Rated operation current Ie at DC-13, 125 V (EF007085): 0.27 A
  • Number of safety auxiliary contacts (EF006940): 0
  • Rated operation current Ie at DC-13, 230 V (EF001386): 0.27 A
  • Number of contacts as normally closed contact (EF008255): 2
  • Width sensor (EF007094): 31 mm
  • Height of sensor (EF007283): 30 mm

More info

▲
Door switch typeKey-operatedGuard-lockMaterial housingResinMaterial headResinAmbient temperature (operating)-30-70 °CDirection of operationAdjustableDoor contacts NC2Door contacts NO1Switch actionSlow actionMake before breakLED indicatorConnection methodTerminal blockCable length0 mDegree of protection (IP)IP67Conduit sizeM20Number of conduits1ShapeCuboidOverall length of sensor96 mmHeight of sensor30 mmWidth of sensor31 mm

Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
