View larger
Images are for illustrative purposes only. Please refer to data sheet for details
D4NS-2DF D4NS0014M D4NS2DF OMRON Safety interlock switch, 3NC, 10 A, single G1/2 conduit
D4NS-2DF
D4NS0014M
D4NS2DF
OMRON
1 Pcs.
Safety interlock switch, 3NC, 10 A, single G1/2 conduit
Safety interlock switch, 3NC (slow-action), 10 A, single G1/2 conduit,
Automation > Position switch with separate actuator
D4DL/DS/DH/DR/GL/NL/NH/NS
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲Specifications
| Door switch type | Key-operated |
| Guard-lock | |
| Material housing | Resin |
| Material head | Resin |
| Ambient temperature (operating) | -30-70 °C |
| Direction of operation | Adjustable |
| Door contacts NC | 3 |
| Door contacts NO | 0 |
| Switch action | Slow action |
| Make before break | |
| With LED indicator | |
| Connection method | Terminal block |
| Cable length | 0 m |
| Degree of protection (IP) | IP67 |
| Conduit size | G1/2 |
| Number of conduits | 1 |
| Shape | Cuboid |
| Overall length | 96 mm |
| Height of sensor | 30 mm |
| Width sensor | 31 mm |
| Feature Name | Feature Value |
|---|---|
| Explosion safety category for dust (EF003998) | None |
| Construction type housing (EF004008) | Cuboid |
| Type of switching contact (EF003591) | Slow-action switch |
| Degree of protection (NEMA) (EF011959) | Other |
| Coating housing (EF001601) | Other |
| Degree of protection (IP) (EF005474) | IP67 |
| Type of interface for safety communication (EF003956) | None |
| Type of electric connection (EF003961) | Other |
| Type of interface (EF006977) | None |
| Housing material (EF001596) | Other |
| Explosion safety category for gas (EF003997) | None |
| With status indication (EF001602) | No |
| Suitable for safety functions (EF001597) | Yes |
| Forced opening (EF006694) | No |
| Number of contacts as change-over contact (EF008257) | 0 |
| Number of contacts as normally open contact (EF008256) | 0 |
| Rated operation current Ie at AC-15, 230 V (EF001385) | 3 A |
| Rated operation current Ie at DC-13, 125 V (EF007085) | 0.27 A |
| Number of safety auxiliary contacts (EF006940) | 0 |
| Rated operation current Ie at DC-13, 230 V (EF001386) | 0.27 A |
| Number of contacts as normally closed contact (EF008255) | 3 |
| Width sensor (EF007094) | 31 mm |
| Height of sensor (EF007283) | 30 mm |
| Length of sensor (EF007334) | 96 mm |
| Ambient temperature during operating (EF007515) | -30 °C |
