OMRON D4NS-1FF D4NS-1FF D4NS0021B D4NS1FF OMRON Safety interlock switch, 2NC/1NO (MBB), 10 A, single PG 13.5 conduit View larger
Images are for illustrative purposes only. Please refer to data sheet for details

D4NS-1FF D4NS0021B D4NS1FF OMRON Safety interlock switch, 2NC/1NO (MBB), 10 A, single PG 13.5 conduit

D4NS-1FF

D4NS0021B

D4NS1FF

OMRON

1 Pcs.

Safety interlock switch, 2NC/1NO (MBB), 10 A, single PG 13.5 conduit

Automation > Position switch with separate actuator
D4DL/DS/DH/DR/GL/NL/NH/NS

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Industrial facilities utilize safety interlock switches to prevent machinery from operating while protective doors or maintenance panels remain open. The Omron D4NS-1FF offers dependable electrical switching performance with a cuboid housing layout tailored for standard panel integrations. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Construction type housing (EF004008): Cuboid
  • Type of switching contact (EF003591): Slow-action switch
  • Degree of protection (IP) (EF005474): IP67
  • Type of electric connection (EF003961): Cable entry PG
  • With status indication (EF001602): No
  • Suitable for safety functions (EF001597): Yes
  • Forced opening (EF006694): No
  • Number of contacts as change-over contact (EF008257): 0
  • Number of contacts as normally open contact (EF008256): 1
  • Rated operation current Ie at AC-15, 230 V (EF001385): 3 A
  • Number of safety auxiliary contacts (EF006940): 0
  • Rated operation current Ie at DC-13, 230 V (EF001386): 0.27 A
  • Number of contacts as normally closed contact (EF008255): 2
  • Width sensor (EF007094): 31 mm
  • Height of sensor (EF007283): 30 mm
  • Length of sensor (EF007334): 96 mm

More info

▲
Door switch typeKey-operatedGuard-lockMaterial housingResinMaterial headResinAmbient temperature (operating)-30-70 °CDirection of operationAdjustableDoor contacts NC2Door contacts NO1Switch actionSlow actionMake before breakLED indicatorConnection methodTerminal blockCable length0 mDegree of protection (IP)IP67Conduit sizePG13.5Number of conduits1ShapeCuboidOverall length of sensor96 mmHeight of sensor30 mmWidth of sensor31 mm
