OMRON D4N-4222 D4N-4222 D4N 0086H D4N4222 OMRON Plastic 2NC Sharp Roller Metal M20 View larger
Images are for illustrative purposes only. Please refer to data sheet for details

D4N-4222 D4N 0086H D4N4222 OMRON Plastic 2NC Sharp Roller Metal M20

D4N-4222

D4N 0086H

D4N4222

OMRON

1 Pcs.

Plastic 2NC Sharp Roller Metal M20 Plastic 2NC Brusca Roldana Metal M20 Limit switch, Roller lever (metal lever, resin roller), 2NC (snap-action), 2NC (snap-action), M20 (1-conduit)

Automation > End switch
D4N

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

An Omron D4N-4222 plastic limit switch provides precise mechanical position feedback for safety doors, protective guards, and automated positioning systems. Plant engineers integrate these reliable components into machinery safety loops to ensure that operations halt instantly when hazardous access points are disturbed. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Construction type housing (EF004008): Cuboid
  • Degree of protection (IP) (EF005474): IP67
  • Alignment of the control element (EF008793): Roller cam straight
  • Type of control element (EF006976): Roller lever
  • Type of electric connection (EF003961): Cable entry metrical
  • Switching function (EF000189): Quick-break switch
  • Housing material (EF001596): Plastic
  • Switching function latching (EF007447): No
  • With status indication (EF001602): No
  • Suitable for safety functions (EF001597): Yes
  • Forced opening (EF006694): Yes
  • Output electronic (EF006987): No
  • Number of contacts as change-over contact (EF008257): 0
  • Number of contacts as normally open contact (EF008256): 0
  • Rated operation current Ie at AC-15, 230 V (EF001385): 3 A
  • Rated operation current Ie at DC-13, 125 V (EF007085): 0.55 A

More info

▲
  • Direct opening mechanism and approval by notified body
  • Rugged plastic housing with double insulation
  • Wide range of actuators
  • M12 connectors or terminal block with M20 conduit
