Product Overview
Functioning as a PLC CPU, the CS1H-CPU65H CS1W0184G CS1HCPU65H OMRON CPU 5120 E/S 60KW 128KW Data RS232C coordinates automation tasks and large-scale industrial control architectures. Central processors execute the programmed logic routines that govern input and output modules across complex manufacturing and process control systems.
Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- 5120: 250K steps
- 71: Supports duplex power supply and I/O hot-swapping
- 68: CPU for full dual-redundancy
- CPU for full dual-redundancy, with loop control board: CS1D-CPU67P
- 120K steps: 256K words
- 60K steps: 128K words
- CPU for full dual-redundancy, with loop control board (2): CS1D-CPU65P
- 30K steps: 64K words
- 60K steps (2): 40 ns
- 1280: 30K steps
- 35: Supports duplex power supply and I/O hot-swapping
- 960: 20K steps
- 26: Supports duplex power supply and I/O hot-swapping
- Loop control option board: 50 control blocks max.
- Choose the level of redundancy needed; CPU, power supply, communication
- No special programming or software tools required
- Hot-swapping of I/O units
- All standard CS1 I/O units can be mounted
- Ideal for control of power generators, water supply utilities, 24/7 production.
Specifications & ordering info
Ordering information
Max. Digital I/O points | Program capacity | Data memory capacity | Logic execution speed | Max. I/O units | Additional functions | Order code |
|---|
5120 | 250K steps | 448K words | 20 ns | 80 | - | CS1H-CPU67H |
71 | Supports duplex power supply and I/O hot-swapping | CS1D-CPU67S |
68 | CPU for full dual-redundancy | CS1D-CPU67H |
CPU for full dual-redundancy, with loop control board | CS1D-CPU67P |
120K steps | 256K words | 80 | - | CS1H-CPU66H |
60K steps | 128K words | 80 | - | CS1H-CPU65H |
71 | Supports duplex power supply and I/O hot-swapping | CS1D-CPU65S |
68 | CPU for full dual-redundancy | CS1D-CPU65H |
CPU for full dual-redundancy, with loop control board | CS1D-CPU65P |
30K steps | 64K words | 80 | - | CS1H-CPU64H |
20K steps | - | CS1H-CPU63H |
60K steps | 40 ns | - | CS1G-CPU45H |
1280 | 30K steps | 40 | - | CS1G-CPU44H |
35 | Supports duplex power supply and I/O hot-swapping | CS1D-CPU44S |
960 | 20K steps | 30 | - | CS1G-CPU43H |
10K steps | - | CS1G-CPU42H |
26 | Supports duplex power supply and I/O hot-swapping | CS1D-CPU42S |
Accessories
Description | Remarks | Order code |
|---|
High-speed data collection and storage unit, with CF card slot and Ethernet port | CPU bus unit | CS1W-SPU01-V2 |
High-speed data collection and storage unit, with CF card slot and 2 Ethernet ports | CPU bus unit | CS1W-SPU02-V2 |
Duplex unit, required for CS1D-CPU6_H systems | - | CS1D-DPL01 |
Serial communication option board, 2 x RS-232C | - | CS1W-SCB21-V1 |
Serial communication option board, 1 x RS-232C + 1 x RS422/RS-485 | - | CS1W-SCB41-V1 |
Loop control option board | 50 control blocks max. | CS1W-LCB01 |
Loop control option board | 300 control blocks max. | CS1W-LCB05 |
Replacement battery set, for all CS1 CPUs | - | CS1W-BAT01 |
Compact Flash memory card, 128 MB, for all models (not required for operation) | Industrial grade | HMC-EF183 |
Compact Flash memory card, 256 MB, for all models (not required for operation) | Industrial grade | HMC-EF283 |
Compact Flash memory card, 512 MB, for all models (not required for operation) | Industrial grade | HMC-EF583 |
Compact Flash PC-Card adapter | - | HMC-AP001 |
CX-One, integrated software for programming and configuration of all Omron control system components | - | CX-ONE-AL__C-E |
Connection cable, D-Sub 9-pin PC serial port to PLC peripheral port | length: 2.0 m | CS1W-CN226 |
Connection cable, D-Sub 9-pin PC serial port to PLC peripheral port | length: 6.0 m | CS1W-CN626 |
USB to serial conversion cable | - | CS1W-CIF31 |
