OMRON CP1W-8ET1 CP1W-8ET1 CP1W9271A CP1W8ET1,2 OMRON Module Expansion 8 Outputs PNP View larger
Images are for illustrative purposes only. Please refer to data sheet for details

CP1W-8ET1 CP1W9271A CP1W8ET1,2 OMRON Module Expansion 8 Outputs PNP

CP1W-8ET1

CP1W9271A

CP1W8ET1.2

OMRON

1 Pcs.

Module Expansion 8 Outputs PNP I/O expansion unit, 8 x PNP outputs 0.3 A

Automation > PLC digital I/O-module
CP1

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Omron CP1W-8ET1 is a digital expansion module designed to increase the output capacity of programmable logic controller systems by providing additional transistor-based switching channels. Industrial automation setups commonly rely on such I/O modules to interface controllers with external actuators, indicators, and control devices requiring reliable DC switching. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Type of voltage (input voltage) (EF003033): DC
  • Type of output voltage (EF008222): DC
  • Performance level according to EN ISO 13849-1 (EF007399): Level a
  • Type of digital output (EF003601): Transistor
  • Type of electric connection (EF003961): Screw connection
  • Voltage type (supply voltage) (EF002991): DC
  • Digital inputs configurable (EF008516): No
  • Digital outputs configurable (EF008520): Yes
  • Appendant operation agent (Ex ib) (EF004142): No
  • Appendant operation agent (Ex ia) (EF004141): No
  • Redundancy (EF003156): No
  • Suitable for safety functions (EF001597): No
  • Short-circuit-protection, outputs available (EF003203): No
  • Number of digital outputs (EF001993): 8
  • Output current (EF003202): 0.3 A
  • Width (EF000008): 66 mm

More info

▲
Type of moduleDigital I/ONumber of digital inputs8Digital input typeNoneOFF/ON delay0.1-1 msNumber of digital outputs0Digital output typePNPOutput current0.3 APermitted voltage at output4.5-30 VProduct Height (unpacked)110 mmProduct Width (unpacked)66 mmProduct Depth (unpacked)50 mmProduct Weight (unpacked)250 g
