OMRON CP1W-8ET CP1W-8ET CP1W9270C CP1W8ET,2 OMRON Module Expansion 8 Outputs NPN View larger
Images are for illustrative purposes only. Please refer to data sheet for details

CP1W-8ET CP1W9270C CP1W8ET,2 OMRON Module Expansion 8 Outputs NPN

CP1W-8ET

CP1W9270C

CP1W8ET.2

OMRON

1 Pcs.

Module Expansion 8 Outputs NPN I/O expansion unit, 8 x NPN outputs 0.3 A

Automation > PLC digital I/O-module
CP1

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

An Omron module expansion, part number CP1W-8ET, serves to augment existing control hardware configurations by adding extra digital switching channels to a main controller setup. Such expansion modules are commonly deployed in discrete manufacturing applications where supplementary machinery or monitoring points are integrated into an active system. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Type of voltage (input voltage) (EF003033): DC
  • Type of output voltage (EF008222): DC
  • Performance level according to EN ISO 13849-1 (EF007399): Level a
  • Type of digital output (EF003601): Transistor
  • Type of electric connection (EF003961): Screw connection
  • Voltage type (supply voltage) (EF002991): DC
  • Digital inputs configurable (EF008516): No
  • Digital outputs configurable (EF008520): Yes
  • Appendant operation agent (Ex ib) (EF004142): No
  • Appendant operation agent (Ex ia) (EF004141): No
  • Redundancy (EF003156): No
  • Suitable for safety functions (EF001597): No
  • Short-circuit protection, outputs available (EF003203): No
  • Number of digital outputs (EF001993): 8
  • Output current (EF003202): 0.3 A
  • Width (EF000008): 66 mm

More info

▲
Type of moduleDigital I/ONumber of digital inputs0Digital input typeNoneOFF/ON delay0.1-1 msNumber of digital outputs8Digital output typeNPNOutput current0.3 APermitted voltage at output4.5-30 VProduct Height (unpacked)90 mmProduct Width (unpacked)66 mmProduct Depth (unpacked)50 mmProduct Weight (unpacked)250 g
