View larger
Images are for illustrative purposes only. Please refer to data sheet for details
CP1W-16ET CP1W9257F CP1W16ET,1 OMRON Module Expansion to 16 Outputs NPN
CP1W-16ET
CP1W9257F
CP1W16ET.1
OMRON
1 Pcs.
Module Expansion to 16 Outputs NPN
I/O expansion unit, 16 x NPN outputs 0.3 A
Automation > PLC digital I/O-module
CP1
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲Specifications
| Type of module | Digital I/O |
| Number of digital inputs | 0 |
| Digital input type | None |
| OFF/ON delay | 0.1-1 ms |
| Digital output type | NPN |
| Number of digital outputs | 16 |
| Output current | 0.3 A |
| Height | 90 mm |
| Width | 86 mm |
| Depth | 50 mm |
| Weight | 250 g |
| Feature Name | Feature Value |
|---|---|
| Explosion safety category for dust (EF003998) | None |
| Type of voltage (input voltage) (EF003033) | DC |
| Type of output voltage (EF008222) | DC |
| Performance level according to EN ISO 13849-1 (EF007399) | Level a |
| Type of digital output (EF003601) | Transistor |
| Type of electric connection (EF003961) | Screw connection |
| SIL according to IEC 61508 (EF009889) | None |
| Voltage type (supply voltage) (EF002991) | DC |
| Explosion safety category for gas (EF003997) | None |
| Digital inputs configurable (EF008516) | Yes |
| Digital outputs configurable (EF008520) | No |
| Appendant operation agent (Ex ib) (EF004142) | No |
| Appendant operation agent (Ex ia) (EF004141) | No |
| Redundancy (EF003156) | No |
| Suitable for safety functions (EF001597) | No |
| Short-circuit protection, outputs available (EF003203) | No |
| Number of digital outputs (EF001993) | 16 |
| Output current (EF003202) | 0.3 A |
| Width (EF000008) | 86 mm |
| Number of digital inputs (EF001992) | 0 |
| Height (EF000040) | 90 mm |
| Depth (EF000049) | 50 mm |
| Time delay at signal change (EF002382) | 0.1 ms |
