61F-GP-N8 110VAC 159911 61FGPN8110AC OMRON 8 pins General ON/OFF-110VAC
61F-GP-N8 110VAC
159911
61FGPN8110AC
OMRON
1 Pcs.
Automation > (Fill) level monitoring relay
Monitoring Relays
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
A general purpose floatless level switch utilizes electrode probes to manage ON and OFF cycles for liquid transfer applications in water treatment and municipal engineering. This Omron 61F-GP-N8 110VAC unit provides reliable conductive liquid detection for purified or industrial water systems. Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Ordinary purified water or sewage water: General purpose type
- 4 km 1: 61F-GP-N8L 230AC 4KM
- 61F-GP-N8R 110AC 61F-GP-N8R 230AC DIN-rail mounting socket: PF083A-E
- Back-connecting socket: PL08
- Electrode separators: Number of electrodes
- 3: F03-14 3P
- Electrodes, connecting, and lock nuts Applicable liquids: Material
- Purified city water, industrial water, sewage: Equivalent to SUS 304 (AISI-304)
- Connecting nut: −
- Lock nut: −
- Supply voltage: 24, 100, 110, 120, 200, 220, 230 or 240 VAC
- 50/60 Hz: Operating voltage range
- 85 to 110% of rated voltage: Interelectrode voltage
- 8 VAC: Interelectrode current
- Approx. 1 mA AC max.: None
More info
▲Compact plug-in (8-pin) level controller
The 61F-GP-N8 can be used for single- or two-point level control of conductive materials, both liquids and solids. These products are equipped with a red LED operation indicator.
- Low-voltage (AC) electrodes (8VAC or 24VAC)
- Operation range: 4-15kΩ, 70-300kΩ
- Detection method: conductive
- Probes need to be ordered separately
- Conforms to EMC and LVD directives, UL/CSA approved
Ordering information
Ordinary purified water, where the distance between sewage pumps and water tanks or | 2 km1 | ||
4 km1 | |||
Liquids with high specific resistance such as distilled water | |||
Liquids with low specific resistance such as salt water, sewage water, acid chemicals, | |||
Ordinary purified or sewage water, with two-wired-type electrode holder | |||
Accessories
Specifications
1 A, 250 VAC (inductive load: cosφ = 0.4), 3 A, 250 VAC (resistive load) | |||||
Electrical: 100,000 operations min., mechanical: 5,000,000 operations min | |||||
