OMRON CK3W-AD3100 CK3W-AD3100 CK3W0023F CK3WAD3100 OMRON CK3W Analog IN, 8 points, +/-10 V, 16 bit (full scale) View larger
Images are for illustrative purposes only. Please refer to data sheet for details

CK3W-AD3100 CK3W0023F CK3WAD3100 OMRON CK3W Analog IN, 8 points, +/-10 V, 16 bit (full scale)

CK3W-AD3100

CK3W0023F

CK3WAD3100

OMRON

1 Pcs.

CK3W Analog IN, 8 points, +/-10 V, 16 bit (full scale)

Automation > PLC analogue I/O-module
CK3M Multi-axis Controller

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

An Omron CK3W Analog IN, 8 points, +/-10 V, 16 bit (full scale), carrying part number CK3W-AD3100, is engineered to collect high-precision voltage measurements within advanced motion and machine control systems. Multi-channel input units allow controllers to monitor several analog variables simultaneously for synchronized automation tasks. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Type of electric connection (EF003961): Spring clamp connection
  • Output, current (EF003212): No
  • Input, resistor (EF003206): No
  • Input, voltage (EF003205): Yes
  • Input, thermocouple (EF003208): No
  • Analogue inputs configurable (EF008518): No
  • Input, current (EF003204): No
  • Analogue outputs configurable (EF008519): No
  • Input, resistance thermometer (EF003207): No
  • Input signal, configurable (EF003209): Yes
  • Output signal configurable (EF003214): No
  • Output, voltage (EF003213): No
  • Number of analogue inputs (EF001994): 8
  • Number of analogue outputs (EF001995): 0
  • Width (EF000008): 31.6 mm
  • Resolution of the analogue inputs (EF003575): 16 Bit

More info

▲
Type of moduleAnalog I/ONumber of analog inputs8Linear analog input type-10 to 10 VResolution of the analog inputs16 BitProduct Height (unpacked)90 mmProduct Width (unpacked)31.6 mmProduct Depth (unpacked)80 mmProduct Weight (unpacked)133 g

Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
