CJ1W-NC481 CJ1W0343D CJ1WNC481 OMRON Module Positioner 4-axis ETHERCAT (CJ1 and CJ2)
CJ1W-NC481
CJ1W0343D
CJ1WNC481
OMRON
1 Pcs.
Automation > PLC function/technology module
PLC based
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
The Omron CJ1W-NC481 positioner module directs multi-axis servomotor systems and peripheral drives via high-speed EtherCAT fieldbus communications. Industrial positioning modules are frequently integrated into automated packaging machines, material handlers, and CNC systems for precise motion profiling. Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- I/O system: CJ I/O Bus
- Expansion unit type: CPU Bus Unit
- Type of module: Positioning
- Max. number of PTP axes: 4
- Max. number of remote I/O nodes: 16
- Communication port(s): EtherCAT Master
- Height: 90 mm
- Width: 31 mm
- Depth: 65 mm
- Weight: 110 g
- Performance level according to EN ISO 13849-1 (EF007399): Level a
- Suitable for counting (EF003248): No
- Suitable for welding control (EF003251): Yes
- Suitable for multi-axis positioning (EF003267): Yes
- Suitable for flux measurement (EF003261): No
- Suitable for weighing (EF003249): No
More info
▲Specifications
| I/O system | CJ I/O Bus |
| Expansion unit type | CPU Bus Unit |
| Type of module | Positioning |
| Max. number of PTP axes | 4 |
| Max. number of remote I/O nodes | 16 |
| I/O connection type | Other |
| Detachable I/O connector | |
| Suitable for safety functions | |
| Communication port(s) | EtherCAT Master |
| Height | 90 mm |
| Width | 31 mm |
| Depth | 65 mm |
| Weight | 110 g |
