OMRON CJ1W-OA201 CJ1W-OA201 CJ1W0305A CJ1WOA201,1 OMRON Module 8 Outputs Triac Term. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

CJ1W-OA201 CJ1W0305A CJ1WOA201,1 OMRON Module 8 Outputs Triac Term.

CJ1W-OA201

CJ1W0305A

CJ1WOA201.1

OMRON

1 Pcs.

Module 8 Outputs Triac Term. Digital output unit, 8 x triac outputs, 250 VAC, 0.6 A, screw terminal

Automation > PLC digital I/O-module
CJ1

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

An Omron CJ1W-OA201 output module bridges controller logic with external actuators, managing load switching in manufacturing machinery. Such components direct electrical current to application endpoints like pilot lamps, small solenoids, and contactors based on instructions from the central processing unit. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Type of voltage (input voltage) (EF003033): DC
  • Type of output voltage (EF008222): AC
  • Performance level according to EN ISO 13849-1 (EF007399): Level a
  • Type of digital output (EF003601): Triac
  • Type of electric connection (EF003961): Screw connection
  • Voltage type (supply voltage) (EF002991): DC
  • Digital inputs configurable (EF008516): No
  • Digital outputs configurable (EF008520): No
  • Appendant operation agent (Ex ib) (EF004142): No
  • Appendant operation agent (Ex ia) (EF004141): No
  • Redundancy (EF003156): No
  • Suitable for safety functions (EF001597): No
  • Short-circuit protection, outputs available (EF003203): Yes
  • Number of digital outputs (EF001993): 8
  • Output current (EF003202): 0.6 A
  • Width (EF000008): 31 mm

More info

▲
I/O systemCJ I/O BusExpansion unit typeBasic I/O UnitType of moduleDigital I/ONumber of digital inputs0Digital input typeNoneOFF/ON delay1-21 msNumber of digital outputs8Digital output typeTriacPermitted voltage at output170-264 VOutput current0.6 AShort-circuit protected outputsI/O connection typeScrewNumber of I/O connectors1Detachable I/O connectorSuitable for safety functionsNumber of IOV (V+) terminals0Number of IOG (V-) terminals0Number of COM terminals1Product Height (unpacked)90 mmProduct Width (unpacked)31 mmProduct Depth (unpacked)89 mmProduct Weight (unpacked)140 g
