OMRON A22NZ-T-CP A22NZ-T-CP A2275008F A22NZTCP OMRON Accessory Pulsatería A22NZ Block Lighting 24VAC/VDC Push-in+ View larger
Images are for illustrative purposes only. Please refer to data sheet for details

A22NZ-T-CP A2275008F A22NZTCP OMRON Accessory Pulsatería A22NZ Block Lighting 24VAC/VDC Push-in+

A22NZ-T-CP

A2275008F

A22NZTCP

OMRON

20 Pcs.

Accessory Pulsatería A22NZ Block Lighting 24VAC/VDC Push-in+ A22N Lighting Units, 24 VAC/DC, push-in terminal

Automation > Lamp holder block for control circuit devices
A22

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

An Omron block lighting accessory provides the necessary base and terminal interface for illuminating command and control devices on industrial machinery. Such units snap behind pushbuttons to deliver clear visual cues for operators in manufacturing plants.

Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Connection type auxiliary circuit (EF006820): Spring clamp connection
  • Voltage type for actuating (EF008242): AC/DC
  • Lamp type (EF002423): LED
  • With integrated voltage decreasing resistor (EF001399): No
  • Transformer integrated (EF001358): No
  • With integrated diode (EF001400): No
  • With light source (EF005905): No
  • Rated voltage Ue at DC (EF007031): 21.6 V
  • Rated voltage Ue at AC 60 Hz (EF007030): 21.6 V
  • Rated voltage Ue at AC 50 Hz (EF007029): 21.6 V

More info

▲
  • Variety of bezel and color options with aesthetic design.
  • Mounting depth less than 46.8 mm below panel.
  • Up to 6 contact blocks (3 contact blocks across and 2 rows deep).
  • Symmetrical contact block.
  • Push-in Plus terminal block type.
  • Snap-in switch unit for quick and easy mounting.
  • RoHS compliant.
