OMRON A22NE-MP-N A22NE-MP-N A22E0009H A22NEMPN OMRON Emergency stop pushbutton, 40 mm diameter, lock-out, press/release the p.. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

A22NE-MP-N A22E0009H A22NEMPN OMRON Emergency stop pushbutton, 40 mm diameter, lock-out, press/release the p..

A22NE-MP-N

A22E0009H

A22NEMPN

OMRON

10 Pcs.

Emergency stop pushbutton, 40 mm diameter, lock-out, press/release the pull, IP65 Emergency stop button, 40 mm diameter, push-lock/pull-off, IP65 Emergency stop switch, 40 mm dia., push-lock/pull-reset, IP65

Automation > Front element for mushroom push-button
Others

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

An Omron emergency stop pushbutton (part number A22NE-MP-N) features a 40 mm diameter cap with a pull-release unlocking mechanism, ensuring safe shutdown capabilities for industrial machinery control circuits.

Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Colour front ring (EF002429): Black
  • Type of button (EF001546): Flat
  • Colour button (EF000190): Red
  • Degree of protection (IP) (EF005474): IP65
  • Construction type lens (EF006253): Round
  • Material front ring (EF005972): Plastic
  • Unlocking method (EF001403): Pull-release
  • With front ring (EF006014): No
  • Spring-return (EF001407): No
  • Switching function latching (EF007447): Yes
  • Suitable for emergency stop (EF001433): Yes
  • Suitable for lighting (EF001142): No
  • Height opening (EF004778): 22.3 mm
  • Width opening (EF004565): 22.3 mm
  • Hole diameter (EF000079): 22.3 mm
  • Diameter cap (EF001423): 40 mm

Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
