View larger
A165E-S-02 (STOP) A16E7018A A165ES02STOP OMRON Emergency stop button 16mm DPST-NC D30mm text STOP
A165E-S-02 (STOP)
A16E7018A
A165ES02STOP
OMRON
5 Pcs.
Automation > Emergency stop complete
Others
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲Emergency stop switch
The A165E line-up offers E-Stop switches with various head types. For flexible application, a wide range of accessories is provided. To set up easy installation and maintenance, various contact combinations are available.
- Direct opening mechanism with minimum contact separation of 3mm
- Safety lock mechanism prevents misuse
- Short mounting depth
- Modular construction; easy installation using snap-in switch
Ordering information
Note:The above models have a surface indication of “RESET.” Models with “STOP” indication are also available. For further information, contact your Omron representative.
Accessories (order separately)
Used for covering the panel cutouts for future panel expansion. | |||
Useful for repetitive mounting. Be careful not to tighten excessively. | |||
Specifications
1,000 VAC, 50/60 Hz for 1 min between terminals of same polarity | ||
Operating: -10 to 55°C (with no icing or condensation) | ||
| Feature Name | Feature Value |
|---|---|
| Mounting method (EF000003) | Built-in |
| Degree of protection (NEMA) (EF011959) | Other |
| Degree of protection (IP) (EF005474) | IP65 |
| Connection type auxiliary circuit (EF006820) | Soldering flag connection |
| Unlocking method (EF001403) | Turn-release |
| With lighting (EF003829) | No |
| Number of contacts as normally open contact (EF008256) | 0 |
| Number of contacts as normally closed contact (EF008255) | 2 |
| Hole diameter (EF000079) | 16 mm |
| Diameter cap (EF001423) | 30 mm |
