View larger
61F-GP-NE1 220VAC 683843 61FGPNE1AC220 OMRON Driver level well Enchuf. 220Vac
61F-GP-NE1 220VAC
683843
61FGPNE1AC220
OMRON
1 Pcs.
Automation > (Fill) level monitoring relay
Monitoring Relays
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲Compact plug-in (8-pin) level controller
The 61F-GP-N8 can be used for single- or two-point level control of conductive materials, both liquids and solids. These products are equipped with a red LED operation indicator.
- Low-voltage (AC) electrodes (8VAC or 24VAC)
- Operation range: 4-15kΩ, 70-300kΩ
- Detection method: conductive
- Probes need to be ordered separately
- Conforms to EMC and LVD directives, UL/CSA approved
Ordering information
Application | Type | Order code | |
|---|---|---|---|
Ordinary purified water or sewage water | General purpose type | 61F-GP-N8 24AC | |
61F-GP-N8 110AC | |||
61F-GP-N8 230AC | |||
Ordinary purified water, where the distance between sewage pumps and water tanks or | Long-distance type | 2 km | 61F-GP-N8L 230AC 2KM |
4 km | 61F-GP-N8L 230AC 4KM | ||
Liquids with high specific resistance such as distilled water | High sensitivity type | 61F-GP-N8H 24AC | |
61F-GP-N8H 110AC | |||
61F-GP-N8H 230AC | |||
Liquids with low specific resistance such as salt water, sewage water, acid chemicals, | Low sensitivity type | 61F-GP-N8D 24AC | |
61F-GP-N8D 110AC | |||
61F-GP-N8D 230AC | |||
Ordinary purified or sewage water, with two-wired-type electrode holder | Two-wired type | 61F-GP-N8R 24AC | |
61F-GP-N8R 110AC | |||
61F-GP-N8R 230AC | |||
DIN-rail mounting socket | PF083A-E | ||
Back-connecting socket | PL08 | ||
Accessories
Electrode holders | |||||||
|---|---|---|---|---|---|---|---|
Applications | Mounting | Insulator | Max. temperature | Number of electrodes | Order code | ||
For city water and other general use. | Flange | Phenol resin | 70°C | 3 | PS-3S | ||
When mounting space is limited. | Screw | Phenol resin | 3, 300 mm 3, 1,000 mm | PS-31-300MM | |||
Use for sewage, sea water, etc., | Flange | PPS | 150°C (without water drips or vapour on the electrode holder surface) | 1 | BF-1 | ||
For resistance to high pressure. | Screw | PFA | 250°C (without water drips or vapour on the surface of the electrode holder) | 1 | BS-1 | ||
Electrode separators | Number of electrodes | Order code | |||||
1 | F03-14 1P | ||||||
3 | F03-14 3P | ||||||
Electrodes, connecting, and lock nuts | |||||||
Applicable liquids | Material | Component | Indication mark | Inscription | Order code | ||
Purified city water, industrial water, sewage | Equivalent to SUS 304 | Electrode (1 m long) | 1 line | − | F03-01 SUS201 | ||
Connecting nut | − | − | F03-02 SUS201 | ||||
Lock nut | − | − | F03-03 SUS201 | ||||
Purified city water, industrial water, sewage, | SUS316 | Electrode (1 m long) | 2 lines | − | F03-01 SUS316 | ||
Connecting nut | − | 6 | F03-02 SUS316 | ||||
Lock nut | − | 316 | F03-03 SUS316 | ||||
Specifications
Item | 61F-GP-N8 | 61F-GP-N8L | 61F-GP-N8H | 61F-GP-N8D | 61F-GP-N8R |
|---|---|---|---|---|---|
Supply voltage | 24, 100, 110, 120, 200, 220, 230 or 240 VAC; 50/60 Hz | ||||
Operating voltage range | 85 to 110% of rated voltage | ||||
Interelectrode voltage | 8 VAC | 24 VAC | 8 VAC | ||
Interelectrode current | Approx. 1 mA AC max. | Approx. 0.4 mA AC max. | Approx. 1 mA AC max. | ||
Power consumption | Approx. 3.5 VA max. | ||||
Response time | Operate: 80 ms max., release: 160 ms max. | ||||
Cable length | 1 km max. | 2 km max. 4 km max. | 50 m max. | 1 km max. | 800 m max. |
Control output | 1 A, 250 VAC (inductive load: cosφ = 0.4), 3 A, 250 VAC (resistive load) | ||||
Ambient temperature | Operating: −10 to 55°C | ||||
Life expectancy | Electrical: 100,000 operations min., mechanical: 5,000,000 operations min | ||||
Size in mm (H×W×D) | 49.9×38×70 | ||||
