OBO BETTERMANN 605 9 G 605 9 G 1018094 OBO BETTERMANN Attaching clip two lobe, 9mm, Electrogalvanised, DIN 50961, Steel, St View larger
Images are for illustrative purposes only. Please refer to data sheet for details

605 9 G 1018094 OBO BETTERMANN Attaching clip two lobe, 9mm, Electrogalvanised, DIN 50961, Steel, St

605 9 G

1018094

OBO BETTERMANN

100 Pcs.

Attaching clip two lobe, 9mm, Electrogalvanised, DIN 50961, Steel, St Fastening clip 605, medium duty, G. Two lobe fastening clips for cables and pipes.* Sizes 7 to 12 not suitable for bolt-firing tool.

Cables > Pipe saddle clamp
Pizza metal fixation

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Obo Bettermann 605 9 G attaching clip two lobe organizes and fastens small-diameter conduits securely along industrial machine housings and infrastructure walls. Two-lobe support hardware evenly distributes clamping pressure across the outer diameter of installed conduits. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • CO2 Footprint (GWP) Cradle-to-Gate: 0,0073 kg CO2e / 1 Piece
  • Dimension: 9mm
  • Dimension A: 34 mm
  • Dimension B: 23 mm
  • Dimension b: 10 mm
  • Dimension D: 9 mm
  • Dimension d: 4,5 mm
  • Dimension e: 6 mm
  • Dimension H: 8 mm
  • Dimension t: 1 mm
  • Distance to the wall: no
  • Fastening type: Screw hole
  • For diameter: 9
  • Halogen-free: yes
  • Height: 8 mm
  • Hole size: 4,5 x 6 mm

More info

▲
CO2 Footprint (GWP) Cradle-to-Gate0,0073 kg CO2e / 1 Piece
Dimension9mm
Dimension A34 mm
Dimension B23 mm
Dimension b10 mm
Dimension D9 mm
Dimension d4,5 mm
Dimension e6 mm
Dimension H8 mm
Dimension t1 mm
Distance to the wallno
Fastening typeScrew hole
For diameter9
Halogen-freeyes
Height8 mm
Hole size4,5 x 6 mm
Length34 mm
MaterialSteel
Material thickness1 mm
Nominal diameter9 mm
Number of cables/pipes1
Plastic-coveredno
Suitable in fire protection areano
SurfaceElectrogalvanized
UV-resistantyes
Version forTwo-lobe
Width10 mm
