OBO BETTERMANN EDR 40 32-40 LGR EDR 40 32-40 LGR 2011546 OBO BETTERMANN Plug-in seal for pipes, Ø40/32-40, Light grey, 7035, Polyvinylchlori.. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

EDR 40 32-40 LGR 2011546 OBO BETTERMANN Plug-in seal for pipes, Ø40/32-40, Light grey, 7035, Polyvinylchlori..

EDR 40 32-40 LGR

2011546

OBO BETTERMANN

25 Pcs.

Plug-in seal for pipes, Ø40/32-40, Light grey, 7035, Polyvinylchloride, PVC Plug-in seal for pipes, light grey. Plug-in seal for junction boxes for direct insertion of metric pipes

Cables > Cable plug sealing clamp
junction boxes

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

An EDR 40 32-40 LGR 2011546 OBO BETTERMANN Plug-in seal for pipes, Ø40/32-40, Light grey, 7035, Polyvinylchlori.. is integrated into junction boxes and panels to create a dependable seal around inserted pipes and conduits. Such elements are essential for preventing environmental ingress in cable routing infrastructure.

Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • CO2 Footprint (GWP) Cradle-to-Gate: 0,0517 kg CO2e / 1 Piece
  • Colour: Light grey
  • RAL: 7035
  • Dimension: Ø40/32-40
  • Dimension A: 2,2 mm
  • Dimension D1: 46 mm
  • Dimension D2: 42,3 mm
  • Dimension D3: 31 mm
  • Dimension D4: 39,2 mm
  • Dimension L: 49 mm
  • for diameter, max.: 40 mm
  • for diameter, min.: 32 mm
  • for wall thickness, max.: 2,2
  • for wall thickness, min.: 2,2
  • Halogen-free: yes
  • Material: Thermoplastic elastomer
  • Nominal diameter: 40 mm

More info

▲
CO2 Footprint (GWP) Cradle-to-Gate0,0517 kg CO2e / 1 Piece
ColourLight grey; RAL 7035
DimensionØ40/32-40
Dimension A2,2 mm
Dimension D146 mm
Dimension D242,3 mm
Dimension D331 mm
Dimension D439,2 mm
Dimension L49 mm
for diameter, max.40 mm
for diameter, min.32 mm
for wall thickness, max.2,2
for wall thickness, min.2,2
Halogen-freeyes
MaterialThermoplastic elastomer
Nominal diameter40 mm
Protection ratingIP55
SizeM40
Version forOpen
