2068 L 2M FT 1119656 OBO BETTERMANN Profile rails perforated, slot width 16.5 mm, 2000x35x18, Hot-dip galvan..
AML3518P2000FT
1119656
OBO BETTERMANN
20 m.
Profile rails perforated, slot width 16.5 mm, 2000x35x18, Hot-dip galvanised, DIN EN ISO 1461, Steel, St
Anchor rail AML3518, slot width 16.5 mm, FT, perforated. Central C profile rail for cable routing, in conjunction with clamp clips with a hammerhead foot. Can also be used as suspension construction for cable support systems.
Automation > Mounting rail/-profile
Installation Profile
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
AML3518P2000FT profile rails perforated from Obo Bettermann act as a versatile slotted mounting track used extensively for fastening electrical assemblies and pipe clamps. Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Breakable: no
- Bundle: 20 m
- CO2 Footprint (GWP) Cradle-to-Gate: 1,9412 kg CO2e / 1 Meter
- Dimension: 2000x35x18
- Dimension L: 2000 mm
- Drill hole spacing, centre: 50 mm
- Height: 18 mm
- Length: 2000 mm
- Maintain electrical functions: yes
- Material: Steel
- Material thickness: 1,5 mm
- Profile shape: C profile
- Slot width: 16,5 mm
- Static value A: 1,01 cm²
- Static value ly: 0,44 cm⁴
- Static value lz: 1,84 cm⁴
More info
▲| Breakable | no |
|---|---|
| Bundle | 20 m |
| CO2 Footprint (GWP) Cradle-to-Gate | 1,9412 kg CO2e / 1 Meter |
| Dimension | 2000x35x18 |
| Dimension L | 2000 mm |
| Drill hole spacing, centre | 50 mm |
| Height | 18 mm |
| Length | 2000 mm |
| Maintain electrical functions | yes |
| Material | Steel |
| Material thickness | 1,5 mm |
| Profile shape | C profile |
| Slot width | 16,5 mm |
|---|---|
| Static value A | 1,01 cm² |
| Static value ly | 0,44 cm⁴ |
| Static value lz | 1,84 cm⁴ |
| Static value Wy | 0,42 cm³ |
| Static value Wz | 1,05 cm³ |
| Surface | Hot-dip galvanised |
| Type of perforation | Perforated back |
| Version for | Single profile |
| Width | 35 mm |
| With perforation | yes |
| With toothing | no |
