OBO BETTERMANN V-TEC VM12+ LGR V-TEC VM12+ LGR 2022762 OBO BETTERMANN Cable gland with locknut, M12, Light grey, 7035, Polyamide, PA View larger
Images are for illustrative purposes only. Please refer to data sheet for details

V-TEC VM12+ LGR 2022762 OBO BETTERMANN Cable gland with locknut, M12, Light grey, 7035, Polyamide, PA

V-TEC VM12+ LGR

2022762

OBO BETTERMANN

50 Pcs.

Cable gland with locknut, M12, Light grey, 7035, Polyamide, PA Cable gland, metric thread, set with locknut, light grey. Cable gland with metric connection thread in cap nut design, suitable for junction boxes, housings, distributor cabinets in private and industrial areas. With strain relief and integrated sealing lip, tested according to DIN EN 62444. Protection class IP68. Can be used between –20°C and +65°C. Including locknut.

Cables > Cable gland
Gls Plastic

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Including a matching locknut for secure mounting, the Obo Bettermann V-TEC VM12+ LGR cable gland organizes and protects incoming conductors at enclosure entry points. Cable glands prevent mechanical pull stress from compromising internal electrical connections.

Pricing, availability, and lead time are confirmed per enquiry through an RFQ.

  • Bend protection: no
  • CO2 Footprint (GWP) Cradle-to-Gate: 0,0255 kg CO2e / 1 Piece
  • Colour: Light grey
  • RAL: 7035
  • Dimension: M12
  • Dimension E1 (mm): 16,5 mm
  • Dimension E2: 19 mm
  • Dimension L max.: 23,5 mm
  • Dimension L min.: 18,5 mm
  • Dimension L1: 8 mm
  • Dimension L2: 5 mm
  • Dimension L3: 5 mm
  • explosion-proof: no
  • Fibre-glass reinforced: no
  • Flame-resistant: acc. to VDE 0471/DIN 695 Part 2-1, test temperature 650°C
  • Flat cable gland: no
  • For Ex zone: Without

More info

▲
Bend protectionno
CO2 Footprint (GWP) Cradle-to-Gate0,0255 kg CO2e / 1 Piece
ColourLight grey; RAL 7035
DimensionM12
Dimension E1 (mm)16,5 mm
Dimension E219 mm
Dimension L max.23,5 mm
Dimension L min.18,5 mm
Dimension L18 mm
Dimension L25 mm
Dimension L35 mm
explosion-proofno
Fibre-glass reinforcedno
Flame-resistantacc. to VDE 0471/DIN 695 Part 2-1, test temperature 650°C
Flat cable glandno
For Ex zoneWithout
For Ex zone dustWithout
For Ex zone gasWithout
Halogen-freeyes
Impact-resistantno
MaterialPolyamide
Nominal thread size12
Permitted temperature range, max.65 °C
Permitted temperature range, min.-20 °C
Protection ratingIP68
Sealing area D, max.7 mm
Sealing area D, min.3,5 mm
Sealing insert, multipleno
Splittable glandno
Strain relief optionyes
ThreadM12 x 1,5
Thread increase1,5 mm
Thread length8 mm
Thread typeMetric
Type of sealSealing ring
Unstable torque2 Nm
Version forStraight
WAF 115 mm
WAF 217 mm
With locknutno
